High Quality 2.5KW to 4.0KW Generator Automatic Voltage Regulator(AVR) for ELEPAQ PH1800 & PH2600.
Packing Contents: 1 X AVR-2540EL.
Special Note:
1) It has an alternative sector/curved shape with the same mounting size. Rectangle AVR is complete interchangeable with a sector AVR.
2) A higher output AVR definitely works perfect on a generator of low power output while on the contrary, a low power output AVR CAN NOT be used for a generator of higher power output.
Part Number:
AVR-2540EL.
Note: The capacitor (Condenser Assembly) may be installed separately for some AVRs using two lead wires.
Product Features:
- Built-in Full-Wave Output Bridge Rectification.
- Voltage Output Increase with Loading.
- Stable Voltage Output with Negative Voltage Feedback.
- Over Voltage, Over Current and Short Circuit Protection.
- Large Manual Adjustable Voltage Output Range of 160V ~ 260V for 240V output.
- Maximum Output: DC 90V 2.5A(Red & White Wires Connected to A Carbon Brush).
- Excitation Voltage: 90V(Two Brown Wires of 4-Pin Connector).
- Feedback Voltage: 16 ~ 20V(Sampling Voltage, One Black & One White Wires of 4-Pin Connector).
- Frequency: 50/60Hz.
- AC Voltage Output: 120V/240V.
- Auto Voltage Adjusting Accuracy: ≤ ±1%.
- Maximum Temperature Rise: 130C or 266F.
- Continuous Working Time: ≥ 20 Hours.
- Installation-Center Distance: 99 ± 1mm (about 3 15/16 in).
