Murrelektronik 56006 Cube20 BN-PNIO DI8 PROFINET Bus Node IP20 24V
Description
Bus nodes
DI8 - (BN-PNIO)
PROFINET IO
Connection cables are in the online shop under "Connection Technology".
DI8 - (BN-PNIO)
PROFINET IO
Connection cables are in the online shop under "Connection Technology".
Connect Product
Data cable
Show all
Technical Data
Electrical data | Supply
| Norm operating voltage | IEC/EN 61131-2 |
|---|---|
| Operating voltage DC | 24 V |
| Operating voltage US DC | 24 V |
| Total current US max. | 4 A |
| Total current UA max. | 4 A |
| Current consumption max. | 150 mA |
Electrical data | Input
| Current carrying capacity max. | 0,7 A |
|---|---|
| filter time | 1 ms |
| Type input | PNP (EN 61131-2) |
Industrial Communication
| Machine Option Management | Yes |
|---|
Industrial communication | Bus data
| Supported protocol | PROFINET |
|---|---|
| Address range inputs max. | 1.024 byte |
| Address range outputs max. | 1.024 byte |
Industrial communication | PROFINET
| Conformance Class | B |
|---|---|
| addressing | DCP |
| Specification | V2.2 |
Diagnostics
| Short circuit diagnosis | Yes |
|---|---|
| Overload diagnosis | Yes |
| Diagnostic | Under voltage |
| Diagnostic via BUS | per module and channel |
| Diagnostic via LED | per module |
| LED display | Ethernet connection/data traffic |
Installation
| Connection cross section max. | 2,5 mm² |
|---|
Installation | Pin assignment
| Terminal row X2 | Input |
|---|---|
| Terminal row X3 | Input |
Device protection | Electrical
| Degree of protection (EN IEC 60529) | IP20 |
|---|---|
| Galvanic separation (operating voltage) | Yes |
| Galvanic separation input/output | Yes |
Mechanical data
| Number extension modules max. | 15 |
|---|
Mechanical data | Mounting data
| Height | 117 mm |
|---|---|
| Width | 56 mm |
| Depth | 47 mm |
| Mounting method | geschnappt |
| Suitable for mounting type | (EN 60715), mounting rail |
Environmental characteristics | Climatic
| Operating temperature min. | 0 °C |
|---|---|
| Operating temperature max. | 55 °C |
| Ambient temperature (storage, transport) | -20 °C … 85 °C |
Connection data
Connection types
| Connection type 1 | Ethernet In |
|---|---|
| Connection type 2 | X0 |
| Connection type 3 | X1 |
| Connection type 4 | X2 |
Connection type 1
| Family construction form | RJ45 |
|---|---|
| No. of poles | 8 |
| Gender | female |
| Color contact carrier | black |
| PIN 1 | TD + |
| PIN 2 | TD - |
| PIN 3 | RD + |
| PIN 4 | n.c. |
| PIN 5 | n.c. |
| PIN 6 | RD - |
| PIN 7 | n.c. |
| PIN 8 | n.c. |
Connection type 2
| Family construction form | terminal |
|---|---|
| No. of poles | 6 |
| Gender | female |
| Color contact carrier | colorless |
| Connection | Spring clamp terminals FK |
| PIN 1 | 0 V |
| PIN 2 | 0 V |
| PIN 3 | UB |
| PIN 4 | UB |
| PIN 5 | UI |
| PIN 6 | UI |
Connection type 3
| Family construction form | terminal |
|---|---|
| No. of poles | 6 |
| Gender | female |
| Color contact carrier | colorless |
| Connection | Spring clamp terminals FK |
| PIN 1 | DI 0 |
| PIN 2 | DI 1 |
| PIN 3 | DI 2 |
| PIN 4 | DI 3 |
| PIN 5 | US |
| PIN 6 | 0 V |
Connection type 4
| Family construction form | terminal |
|---|---|
| No. of poles | 6 |
| Gender | female |
| Color contact carrier | colorless |
| Connection | Spring clamp terminals FK |
| PIN 1 | DI 4 |
| PIN 2 | DI 5 |
| PIN 3 | DI 6 |
| PIN 4 | DI 7 |
| PIN 5 | 0 V |
| PIN 6 | 0 V |
Commercial data
| URL Webshop | https://shop.murrelektronik.com/56006 |
|---|---|
| GTIN | 4048879049481 |
| EU-Customs tariff number | 85176200 |
| US-Customs tariff number | 8517620090 |
| ECLASS-6.0 | 27242604 |
| ECLASS-6.1 | 27242608 |
| ECLASS-7.0 | 27242608 |
| ECLASS-7.1 | 27242608 |
| ECLASS-8.0 | 27242608 |
| ECLASS-8.1 | 27242608 |
| ECLASS-9.0 | 27242608 |
| ECLASS-9.1 | 27242608 |
| ECLASS-10.0.1 | 27242608 |
| ECLASS-10.1 | 27242608 |
| ECLASS-11.0 | 27242608 |
| ECLASS-11.1 | 27242608 |
| ECLASS-12.0 | 27242608 |
| ECLASS-13.0 | 27242608 |
| ECLASS-14.0 | 27242608 |
| ETIM-5.0 | EC001604 |
| ETIM-6.0 | EC001604 |
| ETIM-7.0 | EC001604 |
| ETIM-8.0 | EC001604 |
| ETIM-9.0 | EC001604 |
| ETIM-10.0 | EC001604 |
| customs tariff number | 85176200 |
| EAN | 4048879049481 |
| Packaging unit | 1 |
