170Amp Battery Cable Earth Live / Starter Welding PVC Flex Red Black Cable 25mm2 Colours: Red / Black Lengths: Choose from the drop-down menu If you need just the cable with no ends, all you need to do is select the colour from the first dropdown menu, Then on the 2nd dropdown go to the bottom and select 1 metre, if you need more than 1 metre change the quantity to how many metres you need. Manufactured in the UK Plain Copper Conductors - PVC Insulated Manufactured in accordance with BS6862 Part 1 1971, where applicable. Product Features: Multi Strand Flexible Battery/Welding Cable 25mm2 Maximum Current: 170 Amp Strands Diameter (0.292 STD): 0.285mm Nom. Insulation thickness: 2.10mm Approx. Outer Diameter: 10.5mm Suitable of temperatures from -30C to +70C. Ring Size

---

🔋 170Amp Battery Cable

⚫ Earth (Black) / 🔴 Live (Red)

⚡ Starter • Battery • Welding • Split Charge

🚗 Cars • 🚐 Vans • 🚜 4x4 • 🚛 Trucks • 🚚 HGVs • 🚤 Boats • 🚐 Campervans • 🏕 Caravans

High Quality 25mm² (4 AWG) Hi-Flex Plain Copper Battery Cable

---

🎨 Colours

🔴 Red or ⚫ Black

---

📏 Ordering Information

Choose your required Cable Colour • Cable Length • Terminal Configuration from the drop-down menus.

8mm ring terminals are fitted as standard unless otherwise requested.

If you require a different ring terminal size, please message us when placing your order with the size required. If we have the requested size available, we'll be happy to fit it for you.

---

🇬🇧 Manufactured in the UK

Manufactured using premium plain copper conductors with durable PVC insulation for excellent flexibility and reliable power transfer.

Manufactured in accordance with BS6862 Part 1:1971 (where applicable).

---

⭐ Product Features

✔ Multi-Strand Flexible Battery / Welding Cable • 25mm² (4 AWG) • 170 Amp Maximum Current

✔ Suitable for 12V & 24V Systems • Professionally Crimped Heavy Duty Terminals • Plain Copper Conductors

✔ High Quality PVC Insulation • Flexible Construction

---

🔧 Ideal For

✔ Replacing Broken, Cut or Damaged Battery Leads • Upgrading Existing Battery Cables

✔ Positive Battery Leads • Negative Battery Leads • Earth Straps

✔ Starter Motor Cables • Split Charge Systems • Leisure Battery Installations

✔ High Current Power Connections • Marine Wiring • Plant & Agricultural Machinery

Suitable for battery leads, earth straps, starter motor cables, split charge systems, leisure batteries, marine wiring, plant machinery and other high-current power applications.

---

📋 Technical Information

Maximum Current: 170 Amp • Voltage: 12V / 24V • Cable Size: 25mm² (4 AWG)

Cable Type: Multi-Strand Flexible Battery / Welding Cable • Conductor: Plain Copper • Insulation: PVC

Colours: Red or Black • Manufactured: United Kingdom • Standard: BS6862 Part 1:1971 (where applicable)

---

ℹ️ Important Information

Please ensure you select the correct cable colour, length and terminal configuration before placing your order.

If you're unsure which option you require, simply send us a message and we'll be happy to help.

Please Note: Cables are supplied with 8mm ring terminals as standard. Alternative ring sizes may be available on request — please message us when ordering and we'll confirm availability.
