C9300-48P-E Cisco Catalyst 9300 48-Port Gigabit Network Essentials Switch w/ PWR-C1-715WAC Power

Item Description

This auction is for a used C9300-48P-E Cisco Catalyst 9300 48-Port Gigabit Network Essentials witch with PWR-C1-715WAC Power. We currently have multiple units in stock. The devices are USED but are tested and are guaranteed to be in excellent working order. Each is suplied with a 30 days replacement warranty against defects resulting form normal uss.

This listing is for a single unit .

Manufacturer:	Cisco
Model Number:	C9300-48P-E
Condition:	Used
Warranty:	30 Days
Quantity:	One (1)
Quantity Available:	TWENTY (20)
Accessories Included :	2x Notched USA AC Power Cord 1x Rack Mount Kit
Packaging:	Not shipped in original box as pictured

Please see the picture and console output below for more details.

We have a large stock of cisco equipment on hand. Please view our other listings and message us for quotation on additional hardware and options.

Console Output

Switch#show version
Cisco IOS XE Software, Version 17.09.04a
Cisco IOS Software [Cupertino], Catalyst L3 Switch Software (CAT9K_IOSXE),
Version 17.9.4a, RELEASE SOFTWARE (fc3)
Technical Support:
Copyright (c) 1986-2023 by Cisco Systems, Inc.
Compiled Fri 20-Oct-23 10:44 by mcpre

Cisco IOS-XE software, Copyright (c) 2005-2023 by cisco Systems, Inc.
All rights reserved.  Certain components of Cisco IOS-XE software are
licensed under the GNU General Public License ("GPL") Version 2.0.  The
software code licensed under GPL Version 2.0 is free software that comes
with ABSOLUTELY NO WARRANTY.  You can redistribute and/or modify such
GPL code under the terms of GPL Version 2.0.  For more details, see the
documentation or "License Notice" file accompanying the IOS-XE software,
or the applicable URL provided on the flyer accompanying the IOS-XE
software.

ROM: IOS-XE ROMMON
BOOTLDR: System Bootstrap, Version 17.9.2r, RELEASE SOFTWARE (P)

Switch uptime is 9 minutes
Uptime for this control processor is 11 minutes
System returned to ROM by PowerOn
System image file is "flash:packages.conf"
Last reload reason: PowerOn

This product contains cryptographic features and is subject to United
States and local country laws governing import, export, transfer and
use. Delivery of Cisco cryptographic products does not imply
third-party authority to import, export, distribute or use encryption.
Importers, exporters, distributors and users are responsible for
compliance with U.S. and local country laws. By using this product you
agree to comply with applicable laws and regulations. If you are unable
to comply with U.S. and local laws, return this product immediately.

A summary of U.S. laws governing Cisco cryptographic products may be found at:

If you require further assistance please contact us by sending email to

Technology Package License Information:

------------------------------------------------------------------------------
Technology-package                                     Technology-package
Current                        Type                       Next reboot
------------------------------------------------------------------------------
network-essentials      Smart License                    network-essentials
dna-essentials          Subscription Smart License       dna-essentials
AIR License Level: AIR DNA Advantage
Next reload AIR license Level: AIR DNA Advantage

Smart Licensing Status: Smart Licensing Using Policy

cisco C9300-48P (X86) processor with 1310642K/6147K bytes of memory.
Processor board ID FCW2208L001
1 Virtual Ethernet interface
52 Gigabit Ethernet interfaces
8 Ten Gigabit Ethernet interfaces
2 TwentyFive Gigabit Ethernet interfaces
2 Forty Gigabit Ethernet interfaces
2048K bytes of non-volatile configuration memory.
8388608K bytes of physical memory.
1638400K bytes of Crash Files at crashinfo:.
11264000K bytes of Flash at flash:.

Base Ethernet MAC Address          : 68:2c:7b:22:62:80
Motherboard Assembly Number        : 73-17956-07
Motherboard Serial Number          : FOC22063CQF
Model Revision Number              : E0
Motherboard Revision Number        : B0
Model Number                       : C9300-48P
System Serial Number               : FCW2208L001
CLEI Code Number                   : INM2110ARA

Switch Ports Model              SW Version        SW Image              Mode
------ ----- -----              ----------        ----------            ----
*    1 65    C9300-48P          17.09.04a         CAT9K_IOSXE           INSTALL

Switch#
Switch#
Switch#show inventory
NAME: "c93xx Stack", DESCR: "c93xx Stack"
PID: C9300-48P         , VID: V01  , SN: FCW2208L001

NAME: "Switch 1", DESCR: "C9300-48P"
PID: C9300-48P         , VID: V01  , SN: FCW2208L001

NAME: "Switch 1 - Power Supply A", DESCR: "Switch 1 - Power Supply A"
PID: PWR-C1-715WAC     , VID: V02  , SN: DCA2146G9BU

NAME: "Switch 1 - Power Supply B", DESCR: "Switch 1 - Power Supply B"
PID: PWR-C1-715WAC     , VID: V02  , SN: DCA2146GBJ5


Switch#
Switch#
Switch#show environment all
Sensor List: Environmental Monitoring
 Sensor          Location        State               Reading       Range(min-max)
 PS1 Vout        1               GOOD               56111 mV          na
 PS1 Vin         1               GOOD              119000 mV        90 - 264
 PS1 CURin       1               GOOD                 613 mA          na
 PS1 Curout      1               GOOD                 844 mA          na
 PS1 POWin       1               GOOD               69500 mW          na
 PS1 POWout      1               GOOD               47250 mW          na
 PS1 FAN         1               GOOD               10016 rpm         na
 PS2 Vout        1               GOOD               56174 mV          na
 PS2 Vin         1               GOOD              119375 mV        90 - 264
 PS2 CURin       1               GOOD                 461 mA          na
 PS2 CURout      1               GOOD                 609 mA          na
 PS2 POWin       1               GOOD               51000 mW          na
 PS2 POWout      1               GOOD               34125 mW          na
 PS2 FAN         1               GOOD                3120 rpm         na
 SYSTEM INLET    1               GREEN                 33 Celsius   0 - 56
 SYSTEM OUTLET   1               GREEN                 38 Celsius   0 - 125
 SYSTEM HOTSPOT  1               GREEN                 51 Celsius   0 - 125

Switch   FAN     Speed   State   Airflow direction
---------------------------------------------------
  1       1     5440      OK     Front to Back
  1       2     5440      OK     Front to Back
  1       3     5440      OK     Front to Back

SW  PID                 Serial#     Status           Sys Pwr  PoE Pwr  Watts
--  ------------------  ----------  ---------------  -------  -------  -----
1A  PWR-C1-715WAC       DCA2146G9BU  OK              Good     Good     715
1B  PWR-C1-715WAC       DCA2146GBJ5  OK              Good     Good     715

---------------------------------------------------

Switch#
Switch#
Switch#show post
Stored system POST messages:

Switch 1
---------

POST: MBIST Tests : Begin
POST: MBIST Tests : End, Status Passed

POST: CRYPTO Tests : Begin
POST: CRYPTO Tests : End, Status Passed

POST: PHY Loopback: loopback Test : Begin
POST: PHY Loopback: loopback Test : End, Status Passed

POST: SIF Tests : Begin
POST: SIF Tests : End, Status Passed

POST: Inline Power Controller Tests : Begin
POST: Inline Power Controller Tests : End, Status Passed

POST: Thermal, Temperature Tests : Begin
POST: Thermal, Temperature Tests : End, Status Passed

POST: Thermal, Fan Tests : Begin
POST: Thermal, Fan Tests : End, Status Passed

Switch#
