Murr MICO BASIC 8.4 8CH 24V 4A Circuit Breaker 9000-41068-0400000

Product Description

Technical Data

ELECTRICAL DATA | INPUT
Input voltage DC 24 V
Input voltage DC min. 18 V
Input voltage DC max. 30 V
Total current bridge set max. 40 A
ON input voltage control inputs min. 10 V
ON input voltage control inputs max. 30 V
ON pulse length control inputs high min. 20 ms
ELECTRICAL DATA | OUTPUT
Switch-on capacity per channel max. 20 mF
Switching current max. 20 mA
INSTALLATION
Connection cross-section inputs max. 16 mm²
Connection cross-section outputs max. 4 mm²
Connection cross-section control inputs / control outputs max. 2,5 mm²
MECHANICAL DATA | MOUNTING DATA
Height 90 mm
Width 70 mm
Depth 80 mm
Mounting method geschnappt
Suitable for mounting type Mounting rail TH35, (EN 60715)
ENVIRONMENTAL CHARACTERISTICS | CLIMATIC
Operating temperature min. 0 °C
Operating temperature max. 55 °C
Ambient temperature (storage, transport) -40 °C … 80 °C


CONNECTION DATA

CONNECTION TYPE 1
Family construction form Bridging Contact
No. of poles 1
Gender female
Color contact carrier black
PIN 1 24 V DC
CONNECTION TYPE 2
Family construction form Bridging Contact
No. of poles 1
Gender female
Color contact carrier black
PIN 1 0 V
CONNECTION TYPE 3
Family construction form terminal
No. of poles 1
Gender female
Color contact carrier green
Connection Spring clamp terminals FK
PIN 1 24 V DC
CONNECTION TYPE 4
Family construction form terminal
No. of poles 1
Gender female
Color contact carrier green
Connection Spring clamp terminals FK
PIN 1 0 V
CONNECTION TYPE 5
Family construction form terminal
No. of poles 2
Gender female
Color contact carrier green
Connection Spring clamp terminals FK
PIN 1 On
PIN 2 14
CONNECTION TYPE 6
Family construction form terminal
No. of poles 4
Gender female
Color contact carrier green
Connection Spring clamp terminals FK
PIN 1 Out 1
PIN 2 Out 2
PIN 3 Out 3
PIN 4 Out 4
CONNECTION TYPE 7
Family construction form terminal
No. of poles 4
Gender female
Color contact carrier green
Connection Spring clamp terminals FK
PIN 1 Out 5
PIN 2 Out 6
PIN 3 Out 7
PIN 4 Out 8
