AEMC MTX 3293B Digital Multimeter
The AEMC MTX 3293B is an IP67-rated TRMS digital multimeter with a 100,000-count color graphical display, data recording, and 1000 V CAT III/600 V CAT IV safety rating. It measures voltage, current, resistance, frequency, capacitance, and temperature, and also features diode testing, duty cycle and pulse counting functions for advanced electrical troubleshooting.
Detailed Overview
The AEMC MTX 3293B is a rugged, waterproof, and compact digital multimeter designed for professionals who require precise and versatile electrical measurements in any environment. Featuring a high-resolution color graphic display and advanced measurement functions, delivering instant visualization and reliable results every time.
Key Features:
-
Versatile Measurement: Measures AC/DC voltage, resistance, capacitance, temperature, duty cycle, pulse counts, and frequency.
-
High-Resolution Display: Color graphic display with 320 x 240 pixels and trend visualization for easy reading.
-
Robust and Waterproof: IP67-rated for protection against dust and water, suitable for outdoor and tough conditions.
-
Extensive Memory: Stores up to 30,000 measurements with recording and zoom functions.
-
Multiple Communication Options: Connects via USB or optional Bluetooth with Android app support.
Click {{widget type="Magento\Catalog\Block\Product\Widget\Link" anchor_text="here" template="product/widget/link/link_inline.phtml" id_path="product/6297"}} for the version of this multimeter with Bluetooth connectivity. -
Long Battery Life: Rechargeable Ni-MH battery or AA batteries providing up to 100 hours of use.
Benefits:
-
Accurate and Reliable: High-precision measurements for a wide range of electrical parameters.
-
User-Friendly Interface: Intuitive graphic display and easy-to-use controls speed up diagnostics.
-
Durable for Field Use: Designed to withstand harsh environments without compromising performance.
-
Comprehensive Data Logging: Enables detailed analysis and monitoring of electrical systems.
-
Convenient Charging: Operates while charging to minimize downtime.
Upgrade your electrical testing capabilities with the MTX 3293B – a trusted multimeter that combines performance, durability, and ease of use.
Key Benefits
-
✓Fully Tested & Certified
-
✓30-Day Risk-Free Returns
-
✓1-Year Full Warranty
-
✓Professional Calibration Services
-
✓Trade-In Program Available
-
✓Fast & Reliable Delivery
What's in the Box
- 1 x Digital multimeter
- 1 x Soft carry case
- 2 x Color-coded safety leads (red/black)
- 2 x Color-coded test probes (red/black)
- 1 x Quick Start Guide
- 4 x 1.5 V NiMH 2400 mA•h rechargeable batteries (installed)
- 1 x Optical USB cable
- 1 x USB Type A charger
- 1 x USB charging cable
- 1 x Thumb drive with SX_DMM software
- 1 x User manual
Technical Specifications
| Brand | Digital Multimeter |
| Model Number | MTX 3293B |
| Counts | 100,000 |
| Voltage AC/DC/AC+DC | 1000 VAC/DC/AC+DC |
| Current AC/DC/AC+DC | 10 AAC/DC/AC+DC (20 A for 30 s max) |
| Bandwidth AC/AC+DC | 200 kHz |
| Resistance | 100 MΩ |
| Frequency | 10 Hz to 5 MHz |
| Capacitance | 10 mF |
| Continuity | <20 Ω |
| Temperature Range | PT100/1000, K/J TC: (-328 to 1472) °F (-164 to 800) °C; (-40 to 2192) °F (-40 to 1200) °C |
| Diode Test | Normal Diode, Zener, LED |
| VLowZ (Low Input Impedance) | Yes |
| Duty Cycle/Pulse Width/Pulse Counting | Yes |
| Memory Capacity | 30,000 measurements |
| Display | Color Graphical, 320 x 240 pixels |
| Communication | USB (MTX 3293B); USB or Bluetooth (MTX 3293B-BT) |
| Software | SX-DMM (included) |
| Power Source | Charger or 4 x AA Batteries or NiMH batteries (included) |
| Battery Life | AA: 100 h, NiMH: 80 h |
| Operating Temperature | -4 to 158 °F (-20 to 70 °C) |
| Storage Temperature | -32 to 104 °F (-35 to 40 °C) |
| Ingress Protection | IP67 |
| Safety Compliance | NF EN 61010-1, NF EN 61010-2-30 1000 V CAT III, 600 V CAT IV |
