Router LTE RUTX09 (Cat 6), 4xGbE, GNSSTELTONIKA

RUTX09 router

RUTX09 is a LTE-A Cat 6 mobile IoT router with dual SIM slots, carrier aggregation and 4 Gigabit Ethernet interfaces. RUX09 can achieve speeds of up to 300 Mbps and is suitable as a primary, backup Internet source in solutions that require a reliable Internet connection and high data throughput.

The RutOS operating system based on Open WRT provides support for many applications and security functions: firewall, VPN, Ipsec, SNMP, content filtering and many others.

  • Model: RUTX09
  • Type: GSM 3G/4G
  • Data transmission: LTE
  • UMTS network : 850 MHz
  • LTE network : 2500 MHz
  • Aero2 support: No
  • Standards : 802.3u
  • Antenna: Detachable external
  • Management, monitoring, configuration: Cellular features: Multiple PDN, Auto APN, Band lock, SIM switch, Operator black/white list, Data/SMS limits, Network protocols: SMTP, SSLv3, TLS 1.3, ARP, PPP, PPPoE, DHCP, Telnet, Network: Failover (Network backup), VLAN, QoS, Load Balancing, Management and monitoring: WEB UI, CLI, SSH, SMS, TR-069, SNMP, JSON-RPC, MQTT, RMS, Cloud solutions: RMS, FOTA, Telenor, Azure IoT Hub, Cloud of Things, Cumulocity, ThingWorx, NTP: NTP Server, NTP Client, Sync with: External NTP server, GNSS, Moble operator, GNSS: NMEA forwarding, AVL, Geofencing, Services: DDNS, VRRP, Wake On Lan (WOL), WEB lter, UPNP, Network shares (Samba), Trac Logging, Administration: Multi user, Conguration proles, Diagnostics, logs, Conguration backup
  • Security: Authentication: Pre-shared key, digital certificates, X.509 certificates, Firewall: Pre-configured firewall rules can be enabled via WebUI, unlimited firewall configuration via CLI; DMZ; NAT; NAT-T, Attack prevention: DDOS prevention (SYN flood protection, SSH attack prevention, HTTP/HTTPS attack prevention), port scan prevention (SYN-FIN,, SYN-RST, X-mas, NULL flags, FIN scan attacks), VLAN: Port and tag based VLAN separation, Mobile quota control: Custom data limits for both SIM cards, WEB filter: Blacklist for blocking unwanted out websites, Whitelist for specifying allowed sites only, Access control: Flexible access control of TCP, UDP, ICMP packets, MAC address filter
  • Card reader: None
  • I/O ports : 4 x 10/100/1000 Mbit/s
  • SIM card: Mini
  • Power supply: 4pin power socket, 9-50 VDC
  • Software: RutOS (OpenWrt based Linux OS)
  • Environment requirements: Operating temperature: -40 C to 75 C, Humidity during operation: 10% to 90% non-condensing
  • Accessories included: RUTX09 router, 18W power supply, 2 x LTE antenna (swivel, SMA male), GNSS antenna (adhesive, SMA male, 3 m cable), SIM Adapter kit, Ethernet cable (1.5 m), Brief user manual, RMS leaflet
  • Color: Aluminium
  • Dimensions: 115 x 44 x 95 mm
  • Other features: Network support: 4G/LTE (Cat 6), 3G, CPU: Qualcomm, 4 x ARM Cortex A7, 717 MHz, Memory: 256 MBytes Flash, 256 MBytes RAM, GNSS support: GPS, GLONASS, BeiDou, Galileo, QZSS, Status LED: 3 x WAN type, 2 x connection type, 5 x signal strength, 8 x Ethernet, power
  • EAN: 4779027312460
  • Manufacturer: TELTONIKA
