Digital Day Night Thermostat Outlet Plug with Timer, Heating Cooling Multi Period Temperature Controller, LCD Screen Outlet Socket for Reptile Incubator Greenhouse Brewing Refrigerator 110V
About this item
- ✅【Programmable Thermostat】Plug-and-play design, large Backlit LCD screen with wide viewing angle for easy reading. Appearance using PC flame retardant material, high temperature flame retardant. Upgrade Digital Day & Night Thermostat. 4 modes are available. Temperature control range:-40℃~120℃/-40℉~248℉. Time set: 0-24h/daily cycle.
- ✅【TC Mode for Temperature Control】This mode is used for temperature control without specific time periods. Simply set the start temperature and stop temperature, and the thermostat will operate in heating or cooling mode according to the program. (Cooling: Start temperature>Stop temperature; Heating: Start temperature<Stop temperature). Long press and hold "SET" for about 5 seconds to switch between Fahrenheit and Celsius displays.
- ✅【TC +Timer Mode for Day / Night Temperature】Two or three different temperatures can be set for time cycling within 24 hours during the day and night. For example, you can maintain the temperature of the breeding room between 6:00 and 19:00 at 18-21 ℃, and between 19:00 and 6:00 the next day at 22-24 ℃. A maximum of 3 time periods of temperature can be set within 24 hours.
- ✅【Timer Mode & Alarm】Timer mode is used to turn on and off the device in two time periods of 24 hours. For example, from 8:00 to 16:00, turn on the device and turn it off at other times. At the same time, the temperature controller also has high or low temperature alarm and low temperature alarm functions.
- ✅【More Functions】Bulit-in a 3.6V rechargeable battery, it can maintain the clock display for 7 days after power failure. When the battery is exhausted, all data will be saved (except the clock, which needs to be reset). 1.7m/ 5.6ft NTC 10K temperature sensor probe. Temperature calibration. Reset function. The backlight time is adjustable and the keys have a beep sound.
- ✅【 Wide Range of Application 】This thermostat plug socket is widely used for greenhouse, reptile, incubator, terrarium, freezer, refrigerator, heater, fridge, homebrew, vivarium, fermentation, heat mat, and other temperature-controlled system.
Product Description
XIEHUZA Upgrade Day Night Thermostat Outlet Plug with Timer
Specification:
Temperaturbereich: -40~120℃(-40~248℉)
Rated voltage: 110VAC 50HZ
Rated load: MAX 16A 3680W
Temperature range: -40~120℃
Temperature control minimum temperature difference: 1℃
Resolution of the temperature display: 0.1℃
Clock error: <2 minutes/month
Sensor: NTC 10K/B3950
Cable length: about 1.7 meters
|
|
|
|
|---|---|---|---|
TC modeThis mode is for temperature control without a timer set. Set start temperature and stop temperature, when start temperature < stop temperature, the temperature controller plug will work in heating mode; When start temperature > stop temperature, it will work in cooling mode. | TC+Timer modeTwo or three different temperatures can be set for time cycling within 24 hours during the day and night. For example, you can maintain the temperature of the breeding room between 6:00 and 19:00 at 18-21 ℃, and between 19:00 and 6:00 the next day at 22-24 ℃. A maximum of 3 time periods of temperature can be set within 24 hours. | Timer modeWith ON/OFF time setting per day, Timer mode is used to turn on and off the device in two time periods of 24 hours. For example, set Time 1 ON=6:00, Time 2 OFF=20:00, the device will be turned on from 6:00 to 20:00 and turned off from 20:00 to 6:00. | AlarmThe temperature controller also has high or low temperature alarm and low temperature alarm functions. Press the "MODE" button to swithing the "Alam MODE", Press the SET button to sert high temperature alarm and low temperature alarm numerical value. |
More Functions
- Long press and hold "SET" for about 5 seconds to switch between Fahrenheit and Celsius displays.
- LCD screen is different from most other products on the market. It has a backlight function.
- Memory fuction, set parameters will be saved permanently, clock seting will be saved for one week.
- 1.7m/ 5.6ft NTC 10K temperature sensor probe. Temperature calibration. Reset function. The backlight time is adjustable and the keys have a beep sound.
