Features:

• power supply (two power supplies cannot be powered at the same time): Power supply 1, DC 6.5-25V; Power supply 2, DC 5V
• Working current: (Normal Mode) standby current 41mA, working current 83mA; (Energy-Saving mode) Standby current 7mA, working current 44mA.
• There are three input control port: forward control(FWD), erse control( ), and stop control(STOP).
• Two input modes, Low-Pulse mode, Low- mode
• Delay time: 0.1-999.9 seconds, 1-9999 seconds, 1-9999 minutes.
• Cycle times: no cycle, 2-99 cycles, always cycle.
• Three indicators: forward indicator(F LED), erse indicator(R LED), stop indicator(S LED).
• Relay load current, recommended less than 5A.
• This is a multi-function DC/AC motor forward and erse controller with multiple control modes. Many control functions can be derived through reasonable settings.


Port:
DC 5.5MM female : Power supply 1, DC 5V power supply.
VIN: Power 2 positive, DC 6.5-25V power supply
GND: Power supply 2 negative
FWD: Forward input control (partial Function-Mode is invalid)
: erse input control (partial Function-Mode is invalid)
STOP : Stop input control (partial Function-Mode is invalid)
M+: Motor positive
M-: Motor negative
P+: Positive terminal for motor power supply
P-: negative terminal for motor power supply



Specification:

Power supply: DC 6.5-25V, DC 5V

Working current: 83mA

Standby current: 41mA

Relay load current: <5A

Delay time: 0.1-999.9 seconds, 1-9999 seconds, 1-9999 minutes

Size: 8*5cm/3.2*2in
Weight: Approx. 51g/1.8oz

mode:

1 low pulse (falling )

2 low (rising )



Timer:

T1: Forward timer

T2: erse timer

T3: Stop timer

Time unit : 0.1 second, 1 second, 1 minute



Relay action:

Motor forward : Relay 1 is ON, relay 2 is OFF, and the F LED indicator is flashing.

Motor erse : Relay 1 is OFF, relay 2 is ON, and the R LED indicator is flashing..

Motor stop   : Relay 1 is OFF, relay 2 is OFF, and the S LED indicator is flashing.



Factory settings:

Press the "++" and "--" buttons simultaneously for 5 seconds.



Energy-saving mode:

Press and hold the "OK" button for 5 seconds to enter the "Energy-saving mode". Press and hold the "OK" button again for 5 seconds to exit the "Energy-saving mode". Energy saving mode just turns off the digital tube and LED indicator, and other functions are normal.



Function mode:

F-01

After power-on, the motor is forward T1 time; then the motor stops T3 time; then the motor erse T2 time; so it is repeated Nx times. When the STOP port is ed, the motor stops working immediately. (FWD, port is invalid)



F-02

This function is a F-01 variant. F-01 is run directly after power-on, but F-02 needs to FWD or port to run.



F-11(   ersible 1）

the FWD port, the motor is forward T1 time, and automatically stops (in order to the motor, during the delay period, the port to stop T3 time and then erse T2 time, FWD port to re-time T1).

the port, the motor is erse T2 time, and automatically stops (in order to the motor, during the delay period, the FWD port is ed to stop the T3 time and then the T1 time is forward, and the port is re-timed T2).

When the STOP port is ed, the motor stops immediately, regardless of whether the motor is forward or erse.



F-12(   ersible 2）

the FWD port, the motor is forward T1 time and stops automatically (during the delay period, except for ing STOP port, the other ports are invalid).

the port, the motor is erses T2 time, and automatically stops (during the delay period, except for ing STOP port, the other ports are invalid).

When the STOP port is , the motor stops immediately, regardless of whether the motor is forward or erse.



F-21

When the FWD port is low , the motor is forward, and after the FWD port is released, the motor stops.

When the port is low , the motor is ersed, and after the port is released, the motor stops.

In this mode, the FWD and ports cannot be connected low at the same time, and the STOP port is invalid.



F-22

When the FWD port is low , the motor is forward, and after the FWD port is released, the motor stops.

When the port is low , the motor is ersed, and after the port is released, the motor stops.

In this mode, the FWD and ports cannot be connected low at the same time, ing the STOP port, the motor stops immediately.



Parameter setting:

There are three menus: Work Menu, Function Menu, Parameter Menu.

Note: When entering the "Function Menu" or "Parameter Menu", the module still works normally (countdown and the is running normally). The set parameters are valid only after being powered on again.



1 Power on to enter the running state (Work Menu).

If the current function is F-01, then the motor direct run and the digital tube displays the countdown. F-01 is displayed after the is completed.

If the current function is other functions, such as F-11. Then the digital tube displays F-11. After the , the digital tube displays the countdown. After the is completed, F-11 is displayed.

Function mode	Digital tube display	Setting method
Function 01	F1-01	Short press the "SET" button to enter the setting state,then use the "++"button and the "--"button to select the corresponding sub-menu setting,short press the"OK" button to return to the p ious menu
Function 02	F1-02
Function 011	F1-11
Function 012	F1-12
Function 21	F1-21
Function 22	F1-22

  2 In the running state(Work Menu), short press the SET button to enter the "Function Menu" (Above table).

Digital tube bit 1(parameters)	bit2	bit3-4	parameter definition	default parameter
1	-	00-99	Time T1:single digit and tens digit	04
2	-	00-99	Time TI:hundreds digit and thousands digit	00
3	-	00-99	Time T2:single digit and tens digit	02
4	-	00-99	Time T2:hundreds digital and thousands digita	00
5	-	00-99	Time T3:single digit and tens digit	01
6	-	00-99	Time T3:hundreds digit and thousands digit	00
7	-	01-03 01:0.1seconds 02:second 03:minute	time unit	02
8	-	0-99	number of cycles	1
9	-	01-02 01 low pulse  02 low	mode	01

Package list:

1 x Motor Controller board
