Features:

1.  brand new and high quality.

2. Small body and stable performance.

3. This module is programmable and can realize thousands of functions.

4. Work performance is stable and

5. Built-in timing circuit can effectively ensure -term of the module



Specification:

Condition: Brand New

Model: FX1N-20MR

Power Supply: 10-28VDC

Working Voltage: 24VDC

Weight: Approx. 165g / 5.8oz



Function:

1. Turn on the power, the relay 1 is closed after N seconds of closing; then the relay 2 is closed after N seconds of closing.

2. Turn on the power, the relay 1 is turned off after N seconds of closing; then the relay 2 is turned off after N seconds, and then cycles.

3. When the power is turned on, the relays 1 and 2 are not activated. When there is a or a button is ed, the relay 1 is turned off after N seconds is closed; then the relay 2 is turned off after N seconds and then turned off until the , repeating the same action.

By programming the s 1, 2, any control of the relays 1 and 2 can be achieved.

4. When 1 has a , relay 1 is closed and relay 2 is turned off; 5. When 2 has a , relay 1 is turned off and relay 2 is closed.

6. Only the NPN sensor can be connected, and the sensor can be programmed to realize any control of the relay.

7. When 1 has a , control relay 1; when 2 has a , control relay 2.

8. Turn on the power, control the motor to rotate for N seconds, then reverse N seconds, and cycle.

9. When the 1 has a , the motor is controlled to rotate forward; when the 2 has a , the motor is reversed.



Package List:

1 * Relay Module
