Features
  • Real time full motion video transmission over CAT5 cable
  • 720P (450m)/1080P (250m) for HD-CVI Cameras
  • 720P/1080P (250m) for HD-TVI Cameras
  • 720P/960P (320m) for AHD Cameras
  • Tool-less Snap models for easy installation
  • Built in TVS surge protection
  • Fast and easy installation saving time and money
  • Passive baluns do not require power sources
  • Designed for use with unshielded twisted pair, CAT5 or higher
Specification
Frequency response DC to 60MHZ Attenuation 0.5dB typical
CMRR 60dB, crosstalk and noise immunity Impedances BNC Coax:75ohm, CAT5 Coax terminal: 100ohm
Working temperature -10~+70 degrees Celsius Humidity 0% to 95%
Whole length 19cm / 7-1/2" Weight 55g
Package
