Document
Details
  • Features
  • Easy to install and User friendly
  • Can suit both Left and Right hand door (by rotating the lock 180 Degree)
  • Adopting the most advanced mechanical design, production technology in Taiwan
  • Can work with all the intercom system in my store
  • Can work with wood door, steel door, stainless steel door
  • Static electricity power consumption, long service life, strong security
  • Fail Secure Operating Mode (Locked when power removed)
  • High-quality stainless steel
  • High anti-theft and high safety
  • Double lock heads inside and outside
  • With electronic-control unlocking unit and a spring adjusting balance unit
  • Support manual unlocking, 3 keys included
  • Suitable for : home, offices, schools, hotels, factories, warehouses, etc
  • Specification
  • Voltage: DC9~12V, 1.5A
  • Power: > 12W
  • Operating Mode: NO (Locked when power removed)
  • Dimensions (strike):
  • - Approx. 36 (W) x 102 (H) x 51 (D) mm
  • - Approx. 1-3/8" (W) x 4" (H) x 2" (D) inch
  • Dimensions (main body):
  • - Approx. 123 (W) x 105 (H) x 35 (D) mm
  • - Approx. 4-3/4" (W) x 4-1/8" (H) x 1-3/8" (D) inch
More Details
Package
  • 1 x Electric Lock
  • 1 x Key cylinder
  • 3 x Key
  • 1 x Installation Accesssories (Screws)
