ADUM1201 ADUM1201ARZ Magnetic isolator Steady Replace Optocouplers DC3V/5V


Features
Higher speed up to 125Mbps.
Power consumption is lower than 1/10 of the traditional optoisolator at the same data transmission rate, and the minimum operating current is 0.8mA.
Higher performance timing accuracy, transient common mode rejection, and inter-channel matching are better than traditional optoisolators.
Smaller size and higher integration, the printed circuit board (PCB) area is 40% of the traditional optoisolator.
More flexible application Unlike traditional optoisolators, multi-channel digital isolators can provide forward and reverse communication channels within the same chip.

Specification
High temperature operation:125℃
High data rate:DC 25Mbps(NRZ)
High common mode transient immunity:>25kV/us
Power supply voltage:2.7V-5.5V
0.01μF to 0.1μF capacitance required between power supply and reference ground

Bidirectional communication
5V operation :
1. At 0 Mbps to 2 Mbps, the maximum current per channel is 1.1 mA
2. At 10 Mbps, the maximum current per channel is 3.7 mA
3. At 25 Mbps, the maximum current per channel is 8.2 mA
3 V operation:
1. 0.8 mA maximum current per channel at 0 Mbps to 2 Mbps
2. 2.2 mA maximum current per channel at 10 Mbps
3. 4.8 mA maximum current per channel at 25 Mbps

Pin Description
1、VDD1:Supply voltage
2、VOA:Logic output A
3、VIB:Logic input B
4、GND1:Ground
5、GND2:Ground
6、VOB:Logic output B
7、VIA:Logic input A
8、VDD2:Supply voltage

List
1 x Module
