XVR Longse XVRT3004C


EAN    8059916649973
ARTICOLO    101.03.00.001
SPECIFICHE
  • System
Main Processor - MC6630
Operating System - Embedded LINUX
  • Video
Input - Normal Mode: Analog:   4*(TVI/AHD: 5M@12fps;  AHD/TVI/CVI: 4M@15fps;  AHD/TVI:   3M@18fps;  AHD/TVI/CVI: 1080P/720P;  Analog: 960H)
Analog+Network: 2*Analog(TVI/AHD: 5M@12fps;  AHD/TVI/CVI:   4M@15fps;  AHD/TVI: 3M@18fps;  AHD/TVI/CVI: 1080P/720P;    Analog: 960H)+4*network(MAX 2MP)
Network: 9*5MP/4MP/3MP/1080P/960P/720P(Total incoming bandwidth ≤48M)
Input - 4CH BNC
Signal Type - Analog/AHD/CVI/TVI 2.0/TVI   3.0/Network
Output - 1HD,1 VGA
  • Audio
Input - 1 Channel, RCA, support AOC
Two-way Audio - NO
Output - 1 Channel, RCA
  • Alarm
Sensor Input - NO
Output - NO
Motion Detection - 4 Channel(max 9 Channel in pure   network mode)
Trigger Events - Recording,  Email,   Screen tips, Buzzer, Push notifications(motion detection)
Email Alarm - Send Image to The Designated   E-mail
  • AI Function
Human Detection - YES
  • PTZ
Interface - RS485
Protocol - Pelco-D, Pelco-P
Baud Rate - 110~921600
Address - 0~255
  • Display
VGA - Resolution: 1920 ×   1080P/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz,1024 × 768/60Hz
HD Output - Resolution:1920 ×   1080P/60Hz,  1280 × 1024/60Hz, 1280 × 720/60Hz,1024 × 768/60Hz
Display Split - 9 Channel/4 Channel /   1Channel
Privacy Masking - 3 Rectangular Zones (Each   camera)
OSD - Camera title, Time, Video   loss, Alarm, Motion detection, Recording
  • Recording
Video Compression - H.265/H.264
Audio Compression - G.711U/G.711A
Resolution - 5MP_Lite(1296×1952),4MP_Lite(1280×1440),3MP_Lite(1024×1536),1080N(960×1080),720P(1280×720),960H(P:960×576/N:960×480)
Video Quality - Lowest/Low/Ordinary/Good/Better/Best
Record Rate - Analog:    PAL:5MP_Lite(1296×1944 4*8fps),4MP_Lite(1280×1440 4*15fps),3MP_Lite(1024×1536   4*18fps),1080N(960×1080 4*18fps),720P(1280×720 4*20fps), 960H(960×480   4*25fps)
NTSC: 5MP_Lite(1296×1944 4*8fps),4MP_Lite(1280×1440   4*15fps),3MP_Lite(1024×1536 4*18fps),1080N(960×1080 4*18fps),720P(1280×720   4*20fps), 960H(960×480 4*30fps)
Pure IP(H.265):
PAL:   5MP@8×25fps,4MP@9x25fps,3MP@9×25fps,1080P@9×25fps,960P@9×25fps,720P@9×25fps,D1@9×25fps
NTSC: 5MP@8×30fps,4MP@9×30fps,3MP@9×30fps,1080P@9×30fps, 960P@9×30fps,   720P@9×30fps, D1@9×30fps
Record Mode - Manual\Timer\Motion   Detection
  • Playback & Backup
Decode Capability - 2CH 1080P@30fps
Sync Playback - Pure Analog: 4CH 960H@25fps,   2CH 720P@20fps, 2CH 1080N@18fps, 1CH 5M_LITE@8fps, 1CH 4M_LITE@15fps, 1CH   3M_LITE@18fps
Mixture mode:  4CH 720P@25fps, 2CH 1080P@25fps,  1CH 5M_LITE@8fps,   1CH 4M_LITE@15fps, 1CH 3M_LITE@18fps
Pure Network: 4CH*720P@25fps, 2CH 1080P@25fps, 1CH 5MP@25fps
Remote Playback - 1 Channel
Search Mode - ALL, Channel, Manual, Time,   Date, Motion Detection
Playback Functions - Play, Pause, Stop, Fast   play, Slow play, Rewind, Single frame forward/back, Digital Zoom, Full screen
Smart Phone Playback - 4 Channel
Backup Mode - USB Device(with fomat FAT 32   )/Network/FTP
  • Network
Interface - 1 RJ45 10M/100M Adaptive   Ethernet Interface
Network Functions - TCP/IP, HTTP, UPnP, DNS,   NTP, SMTP,DHCP, FTP, DDNS, RTP, RTSP, RTCP
DDNS - Dyndns, changeip, no-ip,   Oray, A-PRESS, MYQSEE, SKDDNS, SMART-EYES, ZEBEYE,HDPROVN
Web Browser - Edge,IE8-11, Google Chrome ,   Firefox ,Safari
CMS Software - Support  Windows 7/   Windows 8/Windows 10
Extra Stream - CIF/D1(1~25fps)
Smart Phone - iPhone, ipad,  Android   ,Android pad
  • Hard Disk Driver
Interface Type - 1 SATA Interface
Capacity - 1 SATA Hard Disk (2.5″/3.5″   SATA, Up to 8TB)
  • General
Language - Simplified Chinese, Traditional   Chinese, English, Polish, Czech, Russian, Thai, Hebrew, Arabic, Bulgarian,   Japanese, German, French, Portuguese,
Turkic, Spanish, Italian, Hungarian,   Romanian, korean, Dutch, Greek, Vietnamese
UTC Control - YES
USB Interface - 2 USB 2.0 Interfaces
Power consumption - DC 12V/2A  ≤4W   (Without Hard Disk)
Working Environment - -10~55℃/10~90%
Dimension (W×D×H) - 260*215*43(mm)
Weight - 2kg (Without HDD)
