3000W High Output Monoblock, Class D Amplifier

• 1 Ohm Stable
• Phase Control
• Class D Amps
• MODEL 3000W High Output MONOBLOCK Amplifier
• Up to 2250 W X 1 RMS @ 1 ohm
• Up to 1125 W X 1 RMS @ 2 ohm
• Up to 563 W X 1 RMS @ 4 ohm
• Up to 4500 W X 1 RMS Strapped Bridged Power @ 2 ohm
• Strapping capability
• Subsonic filter
• Thermal protection circuit
• Subwoofer Level Control
• Switchable Input Sensitivity
• Variable Bass Boost
• Variable Gain Control
• Variable Low Pass Filter

• General Specs
• Channel Configuration - 1 Channel
• Power Supply Type - Mosfet Power Supply
• Amp Topology - Monoblock, Class D


• Performance Specs
• Total Power Output - 3000 Watts
• Peak Power at 1 Ω - 3000 Watts X 1
• Peak Power at 2 Ω - 1500 Watts X 1
• Rms Power at 4 Ω - 563 Watts X 1
• Strapped Power Bridget at 2 Ω - 6000 Watts
• Speaker Impedance - 1 To 8 Ω
• T.H.D. (Total Harmonic Distortion) - 0.01 %
• S/N Ratio (A-Weighted) - 100 dB
• Frequency Response - 15 Hz To 150 Khz ±1 dB


• Connections, Controls, And Processing
• Rca Inputs - 2 Channel
• Pre amp outputs - 2 Channel
• Low Pass Filter - 50 Hz To 150 Hz
• Subsonic Filter - 15 Hz to 40 Hz
• Bass Boost - Variable 0 To 18 dB
• Switchable Phase Control - 0 to 180°
• Subwoofer Level Control - Yes
• Input Sensitivity Switch - Yes
• Strappable - Yes
• Thermal/Overload/Short Protection - Yes


• Measurement
• Width - 10"
• Height - 2.3"
• Length - 13"
