Description:
1: Wide range of applications
2: Small size
3: Simple to use
4: Support DC5-60V power supply
5: It is suitable for ESP32 secondary development and learning, smart home wireless control and other occasions.
1: Wide range of applications
2: Small size
3: Simple to use
4: Support DC5-60V power supply
5: It is suitable for ESP32 secondary development and learning, smart home wireless control and other occasions.
Features:
1. Onboard mature and stable ESP32-WM-32E module, large-capacity 4M Byte Flash;
2. The I/O port and UART program download port of ESP32 module are all led out, which is convenient for secondary development;
3, power supply voltage DC7-60V;
4, Onboard ESP32 module IO0 programmable button and reset button;
5, ESP32 supports the use of Arduino IDE development tools, providing reference programs in the Arduino development environment;
6. On-board 2-way 5V relay, output switch signal, suitable for controlling the load whose working voltage is within AC250V/DC30V;
1 programmable LED and relay indicator onboard.
1. Onboard mature and stable ESP32-WM-32E module, large-capacity 4M Byte Flash;
2. The I/O port and UART program download port of ESP32 module are all led out, which is convenient for secondary development;
3, power supply voltage DC7-60V;
4, Onboard ESP32 module IO0 programmable button and reset button;
5, ESP32 supports the use of Arduino IDE development tools, providing reference programs in the Arduino development environment;
6. On-board 2-way 5V relay, output switch signal, suitable for controlling the load whose working voltage is within AC250V/DC30V;
1 programmable LED and relay indicator onboard.
Package included:
1* Development board
2* Double row needles
1* Single row needle
1* Single Line Cap
1* Development board
2* Double row needles
1* Single row needle
1* Single Line Cap
