ELP 1.3MP LOW LIGHT Webcamera AR0130 1/3 CMOS Sensor 960P High Speed USB2.0 interface Camera with 2.8-12mm varifocal Lens

Features:

*1.3Megapixel CMOS sensor for high quality image.

*High speed USB 2.0 interface for high resolution PC camera interface.

*high pixel technology for sharp image and accurate color reproduction.

*low light performance – ideal for any lighting condition.

*Super small outline and thin profile for embedded applications.

*High frame rate–30 fps in 1280X960 resolution.

*High quality lens, true and undistorted color image.

*Low power consumption – ideal for portable equipment.

*UVC for use in Linux, Windows XP, WIN CE, MAC, SP2 or above.

*Camera with UVC.

Key Specifications:

Module No.	ELP-USB130W01MT-BFV
Module Size	38mm × 38mm 32mm × 32mm
Temperature (Operation)	-20°C to 70°C
Temperature (Stable Image)	0°C to 60°C
Camera Board Assembly technique	SMT (ROSH)
Lens	varifocal lens
Object distance	5CM-100M
Resolution	600LW/PH (Center)
interface	USB 2.0 High Speed
protocol	USB Video Class(UVC)
Power	USB bus power
Operating system request	Win XP\Win7\Win8\Android\Linux\Mac OS
Certifications	FCC and CE
Sensor Type	AR0130 (1/3” )
Active Array Size	1280 *960
Minimal illumination	0.01Lux
Pixel Size	3.75um
Maximum Image Transfer Rate	1280 (H) x 960 (V) pixels MJPEG 15fps 1280 (H) x 720 (V) pixels MJPEG 30fps 800 (H) x 600 (V) pixels MJPEG 30fps 640 (H) x 480 (V) pixels MJPEG 30fps 320 (H) x 240 (V) pixels MJPEG 30fps
S/N Ratio	44dB
Dynamic Range	83.5dB
Shutter	Rolling shutter/ frame exposure
Lens Type
Lens Construction	5G+IR
Focal Length	2.8-12mm varifocal lens
F/No	1.8
BFL(Optical)	6.5mm
FOV	30-150degree
IR Filter	650±10nm
DSP Type	RV1080P
AGC/AEC/AWB/ABF	Auto
Output Formats	YUYV/MJPEG
IR CUT	SUPPORT
Adjustable parameters	Brightness Contrast Hue Saturation Sharpness Gamma White Balance Exposure Focus
Package	LQFN-40pin
USB Cable	1M(2M/3M/5M Optional)

Applications

CMOS sensor for high quality image and low power consumption
