Processor

Intel Bay trail N2840/N2930/J1900,dual Core/Quad Core
2.0GHz,TDP10W

RAM

Support DDR3L-1333MHz,1*SO-DIMM Solt 1.35V Max 8G

Storage

2*SATA,,1*SATA 6G standard socket and 1* MINIPCIE interface Msata
socket

Display

1*VGA,1*HD,Support VGA+HD dual
screen synchronous abnormal display

WIFI

WIFI+4G module (to be
purchased separately)

LAN

2 * Realtek PCI-E bus RTL8106E/RTL8111H gigabit network
card chip

USB

1*USB3.0,3*USB2.0,N2930/J1900:5*USB2.0,1*USB3.0

COM

2 * COM (RS232) default, supports manual switching to
RS485 signal

I/O

1*SPK Pin1*SATA_PWE Pin,1*AUTO_PWR Pin,1*SIM,1*JTXE
Pin,1*JCOM1 Pin,1*GPIO Pin,1*JC12 Pin,1*F-PANEL Pin,1*JC11 Pin,1*SYS-FAN
Pin,1*JCMOS Pin

Power

DC12(2.5 5525)

System

Support Windows
7/8/10/Linux

BIOS

AMI UEFI BIOS

Working
temperature/humidity

0-60 degrees Celsius, 5%
-95% non condensing

Non working
temperature/humidity

-40-80 degrees Celsius, 5% -95% non condensing

Size

120mm*120mm
