Cerwin Vega VCU81 Vega Series 1‑Channel Class‑D Mono Amplifier – 600 W RMS @ 1 Ω, 400 W RMS @ 2 Ω – Compact Micro Amp with Bass Control Knob - Used, Open Box

The Vega Series Amplifiers have solidified their place as the backbone of the Cerwin-Vega Mobile brand, delivering unrivaled performance in a sleek, compact package. Don’t be deceived by their streamlined design—these amplifiers pack a punch with monstrous power output to drive your system to its fullest potential.

Innovation Meets Power
Updated High-Efficiency Full Range Digital Topology: Experience exceptional sound clarity with maximum energy efficiency.
Enhanced Power IR Digital Chipset: Engineered for stability and precision, ensuring consistent performance under any condition.

Engineered for Durability
Conformal-Coated 4-Layer PCB: Protected against moisture and environmental wear for long-lasting reliability.
Water-Resistant Design: Built to withstand the rigors of the road, wherever your journey takes you.

Specifications
POWER RATING
RMS Power (1Ω): 500W
RMS Power (2Ω): 300W
RMS Power (4Ω): 175W

POWER SUPPLY
Power Supply: Full PWM
Power Supply Threshold: 10.0V-17.0V (DC)
Idle Current: (0.7A)

DISTORTION
THD 4 (1KHz @4Ω): 0.05%
S/N Ratio (A weighted @1W): -85 dBA
S/N Ratio (A weighted @FP): -101.1 dBA

INPUT SENSITIVITY
Low Input Level: 200mV-10.0V
High Input Level: 200mV-10.0V

INPUT IMPEDANCE
Low Input Level: 20 KΩ
High Input Level: 20 KΩ

OUTPUT STAGE
Output Impedance: 0.011Ω
Damping Factor (50Hz @ 4Ω): >250
Bandwidth (-3dB): 10Hz-35KHz

CROSSOVER (-12/-24 dB/Oct)
Variable Low-Pass: 40Hz-400Hz
Variable Sub-Sonic: 10Hz-55Hz

FUSE RATINGS
ATC: 25A

DIMENSIONS
L x W x H: 7.7”x 4.02”x 1.4” (195.6mm x 102mm x 36mm)

FEATURES
Full Range Class D IR Chipset
DirectFET Power Mosfet Output Stage
SMD Technology on 4-Layer PCB Board
Water Resistant Conformal PCB Board Coating
1-year Manufacturer's Warranty
