American Bass 10" 2-Ohm 2200W RMS Triple Stack Magnet Subwoofer HD-VELOCITY10-D2

American Bass 10" 2-Ohm 2200W RMS Triple Stack Magnet Subwoofer HD-VELOCITY10-D2

This Listing Includes

• (1) American Bass 10" 2-Ohm Subwoofer HD-VELOCITY10-D2

The American Bass HD Velocity Series 10" subwoofer is engineered for bass enthusiasts who want serious output, durability, and efficiency in a compact high-performance design. Built to handle demanding power levels, this sub delivers deep, clean, hard-hitting bass with the control needed for both daily-driven systems and competition-inspired builds.

At the core of the HD Velocity 10 is a carbon-fiber-enhanced non-pressed paper cone that balances strength and responsiveness for accurate low-frequency reproduction. A massive triple-stacked 315 oz magnet structure provides strong motor force, while the rigid die-cast aluminum basket with a blue finish maintains stability and cooling under high output.

The high-temperature 3.0-inch 4-layer voice coil is designed to handle sustained power levels up to 2200 watts RMS, resisting heat buildup during aggressive play. With a 2-ohm impedance, this subwoofer is ideal for maximizing output from high-power monoblock amplifiers. Whether installed in a compact ported enclosure or a high-output street system, the HD Velocity 10 delivers powerful, controlled bass with authority.

Features

• 10-inch high-performance subwoofer


• 2-Ohm impedance for maximum amplifier efficiency


• Carbon-fiber-reinforced non-pressed paper cone


• Triple-stacked 315 oz magnet motor structure


• High-temperature 3.0-inch 4-layer voice coil


• Die-cast aluminum basket with blue finish


• Designed for ported enclosures and high-output systems

Specifications

• Subwoofer Size: 10 inch


• Impedance: 2 Ohm


• RMS Power Handling: 2200 Watts


• Max Power Handling: 4400 Watts


• Sensitivity: 84.4 dB


• Voice Coil Diameter: 3.0 inches


• Voice Coil Type: 4-Layer High Temperature


• Basket Type: Die-Cast Aluminum


• Magnet Structure: Triple Magnet


• Magnet Weight: 315 oz


• Recommended Ported Enclosure Volume: 1.8 – 2.5 ft


• Cutout Diameter: 9.25 inches


• Mounting Depth: 7.72 inches

Thiele & Small Parameters

• Sd: 31.4


• BL (Tm): 15.111


• Qms: 5.084


• Qes: 0.254


• Qts: 0.242


• SPLo dB: 84.3


• Vas L: 10.404


• Cms: 76.522


• MMS g: 281.774


• MMd: 278.626


• Vd (L): 5.85


• Xmax mm: 12.5

Dimensions

• Total Diameter: 12.80"


• Mounting Diameter: 11.93"


• Cutout Diameter: 11.34"


• Baffle Depth: 0.63"


• Mounting Depth: 9.02"


• Total Depth: 10.59"


• Weight: 38 lbs
