Product Introduction
The 1.2GHz 10W Wireless Video Transmitter (VTX) is designed for FPV racing and long-range drone image transmission. It supports 9 channels, five adjustable power levels, 4–8S battery input, and features an aluminum alloy case with a heatsink and cooling fan for stable long-term performance.
Features
Advantages
-
Frequency range: 1080MHz–1360MHz, 9 selectable channels
-
Adjustable power: 1W / 2.5W / 5W / 7.5W / 10W
-
Smart audio: IRC Tramp protocol
-
Efficient cooling: aluminum alloy case + heatsink + fan
-
Wide voltage support: 15V–36V (4–8S battery)
-
Over-temperature protection: Auto power reduction above 100°C, recovery below 95°C
Applications
-
Long-distance transmission with stable signal
-
Multiple power levels for various flight scenarios
-
Modular design for easy installation
-
Cooling system prevents overheating shutdown
-
Lightweight (48.15g) for improved flight endurance
Specifications Table
-
FPV racing drones
-
Long-range aerial photography systems
-
Industrial inspection drones
-
Security and emergency surveillance platforms
Specifications Table
|
Parameter |
Value/Description |
|
Frequency Range |
1080MHz–1360MHz (9CH) |
|
Output Power |
1W / 2.5W / 5W / 7.5W / 10W adjustable |
|
Input Voltage |
DC 15V–36V (4–8S battery) |
|
Connector Type |
SMA female |
|
Smart Audio |
IRC Tramp |
|
Cooling Method |
Aluminum alloy case + heatsink + fan |
|
Dimensions |
65.8 × 37.3 × 19.3 mm |
|
Weight |
48.15g |
|
Mounting Hole |
20mm × 20mm / Ø2mm |
|
Temperature Prot. |
≥100°C auto power reduction, ≤95°C restore |
RF Power:10W;
Frequency: 1.2Ghz;
Frequency band:
1080Mhz, 1120Mhz, 1160Mhz, 1200Mhz, 1240Mhz, 1280Mhz, 1320Mh, 1360Mhz
