Portable CO H2S Gas Detector Monitor Hydrogen Sulfide Carbon Monoxide Analyzer

Essential details
Customized support:
OEM, ODM
Place of Origin:
China
Display:
large screen LCD
Detection principle:
Electrochemistry ,Catalysis ,Thermal Conductivity ,Infrared
Detection accuracy:
3% FS
Dimensions:
126mm * 66mm * 33mm
Suitable temperature:
-20 ℃ - 60 ℃
Humidity:
5-90% RH
Battery:
3.7V 2000mA lithium-ion rechargeable battery
Degree of protection:
IP65
Certification mark:
Ex ib IIB T3 Gb
Instrument weight:
210g


Product Introduction


  multi-gas detector, is a one gas detecting instrument which can be equipment with one kind gas sensor or several kinds gas sensor for detecting differentgases simultaneously. It adopts dot matrix display technology and various toxic gas sensors. It can be configured with single, two in one, three in one, four in one, five in one or any other four kind toxic gas sensors for working.


 multi-gas detector with LCD display, has high sensitivity and fast response time. With audio sound&light alarm, it adapts to rather complex environment for concentration monitoring. The product is suitable for chemical, pharmaceutical, municipal, water treatment, telecommunications, archeology, laboratories, cold storage, wine and other places.

Products Pare
Detection range
EX:0-100%LEL  O2:0-30%VOL  CO:0-1000PPM  H2S: 0-100PPM
Instrument accuracy
3% FS
Interface Definition
U3 port (USB)
Battery
3.7V 2000mA lithium-ion rechargeable battery
Lasting time
about 8 hours for flammable gas, about 200 hours toxic gas
Display
Display: large screen LCD
Alarm
sound, light, vibration triple alarm
Direct reading
instantaneous value
Explosion-proof mark:
Ex ib IIB T3 Gb
Degree of protection
IP65
Measurement Permit:
Yu No. 01000109
xplosion-proof certificate number
CNEx12.3661x.
Working temperature:
-20 ℃ - 60 ℃
Instrument size:
126mm * 66mm * 33mm
Working humidity
Working humidity: 5-90% RH
Instrument weight:
210g
Patent No
200530041519.x
Copyright Certificate
No. 0958931
Domestic mark
PA, MC, EX, IP, ISO
Product Feature

Sound and light vibration alarm when boot up, sensor self-test

Large-screen digital display

Convenient to carry, sound, light, vibration alarm

Safety tips: regular flashing, voice prompts

Upload to computer function (optional)

3000 alarm record inquiry function

Easy to use, simple operation

Support 5 kinds of gas real-time detection (customized)
