SZ02 Smart Digital Multimeter 6000 Counts True RMS Auto Electrical Capacitance Meter Temp Resistance Transistor Testers
A.Overview:
Automatic selection of measuring function and range.
Full range oveload protection.
Max. display value:SZ01 6000 digits/SZ02 9999 digits
Automatic shut down time:15 minutes
Sampling time: about 3 times/second
power supply:2*1.5V AAA Battery (Without)
SZ01:The max voltage between the measuring end and the ground is 600V DC or 600V AC.
SZ02:The max voltage between the measuring end and the ground is 1000V DC or 750V AC.
The instrument specifies one year as a cycle,and shall be re-calibrated under 18℃~28℃,with relative humidity less than 75%.
B.Specification:
|
Model |
SZ02 |
SZ01 |
|
AC Current |
999.9mA/10A |
600.0mA/10A |
|
DC Current |
999.9mA/10A |
600.0mA/10A |
|
DC Voltage |
600.0mV/9.999V/99.99V/999.9V |
600.0mV/6.000V/60.00V/600.0V |
|
AC Voltage |
600.0mV/9.999V/99.99V/999.9V |
600.0mV/6.000V/60.00V/600.0V |
|
Line on-off Test |
1Ω |
1Ω |
|
Resistance |
999.9Ω/9.999kΩ/99.99kΩ/ |
600.0Ω/6.000kΩ/60.00kΩ/ |
|
Diode Test |
1V |
1V |
|
Capacitor |
9.999nF999.9nF/9.999uF/ |
|
|
NCV |
YES |
YES |
|
Temperature |
-40~1000℃ |
NO |
|
|
-40~1832℉ |
NO |
|
Frequency |
100Hz/1000Hz |
100Hz/1000Hz |
|
Backlight |
yes |
yes |
Actual parameters are subject to product measurement
C.Package Include:
According to your choice
