Condition: Used
Dimensions: 7.00 x 7.00 x 4.00 inches (L x W x H)
Weight: 0.15 Lbs.

The Cutler-Hammer C25DNB325 is a general-purpose 3-pole definite-purpose contactor designed for use in HVAC systems, industrial machinery, and motor control applications. It features a 120 V AC coil and supports loads up to 25 A across a variety of voltages. Technical specifications: Model: C25DNB325 Manufacturer: Cutler-Hammer (by Eaton) Contactor type: Definite-purpose, 3-pole Coil voltage: 120 V AC, 50/60 Hz Contact rating: 25 A resistive (FLA), 35 A max resistive load per pole Voltage ratings (1 Ø / 3 Ø): – 115 V: 2 HP (1 Ø), 5.5 HP (3 Ø) – 230 V: 2.5 HP (1 Ø), 7.5 HP (3 Ø) – 460 V: — (1 Ø), 10 HP (3 Ø) – 575 V: — (1 Ø), 10 HP (3 Ø) Enclosure: Open frame (panel mount) Terminal type: Screw clamp with fork lugs Auxiliary contacts: Not included (optional snap-on modules available) Certifications: UL Recognized, CSA Certified Country of origin: USA Series: C1 Please review pictures carefully and let us know if you have any questions!
