Condition: Used
Dimensions: 7.00 x 4.00 x 4.00 inches (L x W x H)
Weight: 0.10 Lbs.

Potter & Brumfield K10P-11A15-120 Relay with Socket is a general-purpose, plug-in electromechanical relay designed for industrial control applications. It features a DPDT (2 Form C) contact configuration and is suitable for socket mounting. Contact configuration: DPDT (2 Form C) Coil voltage: 120 VAC Contact rating: 15 A at 120 VAC / 30 VDC Coil resistance: 3.9 kΩ Operate time: 13 ms Release time: 10 ms Contact material: Silver Cadmium Oxide (AgCdO) Mounting type: Plug-in, socket mount Termination style: Quick connect - 0.187" (4.7 mm) Operating temperature range: -45°C to +70°C Coil insulation class: Class B Relay type: Non-latching Dimensions: Approximately 28.2 mm (L) × 21.8 mm (W) × 34.9 mm (H) Weight: Approximately 51 g Compliance: UL E22575, CSA L15734 Part number: K10P-11A15-120 Please review pictures carefully and let us know if you have any questions!
