Bullet Piercing Valve

For Refrigeration, Domestic Fridges and Freezers, Air-Con etc.

This line tap valve can be used on 1/4", 5/16" and 3/8" refrigerant pipework and for R12, R22, R134a and R502 systems although it is also widely used on R600a iso-butane systems.

*Manufacturers Names & Numbers for reference purposes only

To Fit Universal

“Bullet Piercing Valve” utilises the same type of gasket found under the head plate of most air conditioning compressors. When installed, the gasket actually compresses the copper tubing .020″ creating a “Permanent”, leak-proof seal that will withstand any pressure and temperature for the life of the unit.

Application:-

Install on the high side as a “Permanent” valve on the job

The Bullet Piercing Valve will not leak

Install on round suction lines or uneven tubing

Product Details:-

Hex key wrench included – No additional tools required

Non-positional mounting – No adaptor valve required

Precision piercing needle is engineered for concentricity and hardness to insure perfect seating every time

Patented valve gasket application provides 50 times more sealing area than competitive “O” ring types

A sealing force of over 180 inch lbs., torque tested with 500 lbs., pressure tested at 250°F

Requires only a 2″ clearance area for installation and operation

Provided with a corrosion resistant plated and lacquered finish

450 PSI Max (31 Bar)

For

1/4″, 5/16″, 3/8″ tubing.

My part looks different

This can be due to the manufacturer changing suppliers during or after a production run of the appliance. Usually the part may only differ visually by colour but fits just the same. In some cases the manufacturer may have experienced problems in the field and has upgraded the part to prevent a repeat of the early failure of the part, but again should fit the same as the original. There are occasions where a part has been modified and additional alterations may be needed to the appliance for the part to fit, but on these occasions the manufacturer usually supplies release notes and diagrams along with the part to help aid installation.
