Premium Type A 5.5KW to 7.5KW Adjustable Generator Automatic Voltage Regulator(AVR) for Westinghouse Branded 4500/5500/6000/6500 Watt Portable Gasoline Generator Models: WH4500, WH4500C, WH5500, WH5500C, WH6000, WH6000C & WH6000S. It can handle maximum surge power up to 8.5KW. Alternator Rear Cover/Stand & Carbon Brush Assembly NOT Included, and Sold Separately.
Quality Product with Prompt Shipping & Solid After Sales Support! All our orders are shipped out of Atlanta, USA and EDT is about 1 to 3 business days for delivery in most areas of continental states.
Packing Contents: 1 X AVR-5575-WH.
1) A higher output AVR definitely works perfect on a generator of low power output while on the contrary, a low power output AVR CAN NOT be used for a generator of higher power output.
2) Most of Replacement AVRs in the market are rated only 5KW and can only handle a maximum power of 6KW. They are too weak to be used unless the total load of your generator won't exceed 5KW!
3) If our AVR is out of adjustment for your generator, please MANUALLY turn clockwise or counter-clockwise a small bronze screw in a blue rubber part to reach your desirable power output. Clockwise turning is for increasing and counter-clockwise turning for decreasing voltage output. If this does not help you out, please contact with us for tech support.
4) A different 4-hole female plastic connector/coupler may be used on your OEM AVR. If so, please contact with us for tech support.
1) A higher output AVR definitely works perfect on a generator of low power output while on the contrary, a low power output AVR CAN NOT be used for a generator of higher power output.
2) Most of Replacement AVRs in the market are rated only 5KW and can only handle a maximum power of 6KW. They are too weak to be used unless the total load of your generator won't exceed 5KW!
3) If our AVR is out of adjustment for your generator, please MANUALLY turn clockwise or counter-clockwise a small bronze screw in a blue rubber part to reach your desirable power output. Clockwise turning is for increasing and counter-clockwise turning for decreasing voltage output. If this does not help you out, please contact with us for tech support.
4) A different 4-hole female plastic connector/coupler may be used on your OEM AVR. If so, please contact with us for tech support.
5) There may be a capacitor voltage regulator installed in your generator. If so, you shall find a compatible generator capacitor in our eBay Store.
6) If a special Type B 8-wire AVR is used on your generator, you can also find it available in our eBay store. Please understand that a Type A 6-Wire AVR & a Type B 8-wire AVR are incompatible one another!
Part Number:
AVR-5575-WH.
Product Features:
We ship worldwide. Please contact us and confirm international shipping & handling fee for shipping out of USA before you place an order with us.
Warranty:
We warrant our PRODUCTS against manufacturer defects in materials, workmanship and finish under normal use and service for three (3) months from the original date of purchase. Please retain the dated invoice as evidence of the date of purchase. You will need it for any warranty service.
Return:
If you are not satisfied with our items and want to return to us, please contact us for a Return Material Authorization (RMA) number within 30 days of receipt before you arrange for return. We DO NOT accept any return without RMA number. Non-authorized returns will be refused and sent back to YOU at your cost. We do not take return after 30 days of receipt of our product. We offer free replacement and exchange service for the goods after 30 days of receipt.
Part Number:
AVR-5575-WH.
Product Features:
- Built-in Full-Wave Output Bridge Rectification.
- Voltage Output Increase with Loading.
- Stable Voltage Output with Negative Voltage Feedback.
- Over Voltage, Over Current, Over Load and Short Circuit Protection.
- Large Manual Adjustable Voltage Output Range of 160V ~ 260V for 240V output.
- Maximum Output: DC 90V 3.5A.
- Excitation Voltage: 90V ~ 110V.
- Feedback Voltage: 14V ~ 24V with an Average of 18V(Sampling Voltage).
- Frequency: 50/60Hz.
- AC Voltage Output: 120V/240V.
- Auto Voltage Adjusting Accuracy: ≤ ±1%.
- Maximum Temperature Rise: 130C or 266F.
- Continuous Working Time: ≥ 20 Hours.
- Installation-Center Distance: 140 ± 1mm (about 5.5 in).
