Pen Type Leeb Hardness Testing Equipment Leeb Hardness Tester for Metal Steel

Introduction:

• The instrument is a kind of portable measuring instrument; it can be quickly, nondestructive and high accuracy when measuring common metal materials hardness.
• It can be used in the laboratory, as well as the on-site engineering field. It can meet the needs of a variety of measurement through instrument measuring conditions setting.

Application:

• Bearings and other parts;
• Failure analysis of pressure vessel,steam turbine generator group and equipment;
• Heavy work pieces;
• Mechanical or permanent assembly installed;
• The test space is very narrow;
• The original record of formal requirements on test results;

Features:

• Intelligent simple: easy operation,directly shows Leeb scale and Rockwell values
• Small and portable: Small, portable instrument, integrated design without connecting cables, improves the reliability
• Industry highlights, OLED display: Can clear display data under direct sunlight, suitable for all kinds of lighting conditions
• Accurate Measurement: High precision of measurement circuit value error for ±0.5% (HLD=800),repetition rate value for 0.8%
• Support for multiple hardness standard: HL、HV、HRA、HRC、HRB、HB、HS
• Massive capacity data storage: The unprecedented mass storage leads the technology trend. It can save 270 hardness measurement data, each group including average, hardness standard.

Specifications:

• Testing direction:Highly accurate in any impact direction
• Testing Range:(170-960)HLD,(17.9-69.5)HRC,,(19-683)HB,(80-1042)HV,(30.6-102.6)HS,(59.1-88)HRA,(13.5-101.7)HRB
• Hardness Standards: HL、HV、HRA、HRC、HRB、HB、HV、HS
• Accuracy: HLD：±0.5%(800HLD)
• Repeatability Value: HLD：0.8%(800HLD)
• Resolution:128×64 OLED display
• Dimensions: 148mm×40mm×30mm
• Power Supply: Rechargeable lithium battery
• Working Hours :About 10 hours
• Operating temperature: 10-50℃;
• Storage temperature: -30 ℃ -60 ℃; Humidity: 90% max;
