10" 700 Rms Dual 4 Ohm Subwoofer TXX-BDC3-10 Audiopipe

Audiopipe 10" Subwoofer 700 Watt RMS 1400 PMPO 4-Ohm Dual Voice Coil TXX-BDC3-10

This Listing Includes:

• (1) 10" dual 4-Ohm Subwoofer

Prepare to be amazed by the Audiopipe TXX-BDC3 10 Subwoofer. Featuring a triple-stack design, this 10-inch subwoofer delivers thunderous bass and exceptional audio performance. With its sleek black finish, it not only sounds great but also looks stylish in any audio setup. Upgrade your car audio system with this powerhouse subwoofer and experience deep, immersive bass like never before. Get ready to feel the music with Audiopipe's top-notch audio quality.

Features

• Massive 700W RMS/1400W Peak Power -Delivers deep, clean bass for high-performance car audio systems


• 10" High-Performance Subwoofer - Ideal size for compact enclosures with powerful low-end response


• Dual 4-Ohm Voice Coils - Offers flexible wiring options for 1© or 4© configurations


• Triple-Stack Strontium Magnet (132 oz.) - Provides greater magnetic force for increased output and control


• 2.5' 4-Layer TIL Voice Coil - Handles heat and power with durability and clarity under pressure


• Wide Frequency Response: 20Hz - 1000Hz - Covers a broad bass spectrum for punchy and accurate performance


• High Sensitivity (89 dB) - Produces more sound with less power, great for daily driving setups


• Standard 6-3/16" Mounting Depth - Fits most universal and custom enclosures with ease


• Rugged Black Finish - Sleek design built for long-lasting performance in custom audio builds

Specifications:

• Size: 10"


• Power (P.M.P.O): 1400 Watt


• Power (R.M.S): 700 Watts


• Frequency Response: 24-1000 Hz


• Voice Coil Diameter: 2.6" (65.5 mm)


• Voice Coil Height: 1.5" (38 mm)


• Sensitivity: 89dB


• Voice Coil: 2.5" TIL


• Net Weight: 19.82 lb


• Woofer Displacement: 3.40 L / 0.12 cu ft

Thiele/Small Parameters:

• Fs (Hz): 3


• Re (Ohms): 2 x 3.6


• Le (mH): 3.2


• Qts: 0.45


• Qes: 0.51


• Qms: 2.1


• Cms (m/N): 0.9


• Vas (L): 16


• Mms (g): 182


• Mmd (g): 178


• No (%): 0.2


• SPL (1W/1M): 87 dB


• BL (Tm): 25


• Sd (cm): 346


• Krm (m©): 55


• Erm: 0.7


• Kxm (mH): 102


• Exm: 0.67

Magnet & Excursion Specs:

• Strontium Magnet: 8.25lbs. (132 Oz.)


• Magnetic Gap Height: 0.47" (12 mm)


• Linear Excursion (Xmax, peak-to-peak): 0.47" (12 mm)


• Maximum Excursion (peak-to-peak): 0.51" (13 mm)


• Magnet Weight: 132 oz / 4.1 kg


• Magnet Height: 1.97" (50 mm)

Dimensions:

• Nominal Diameter: 10"


• Overall Diameter: 10 1/2"


• Mounting Hole Diameter: 8 7/8"


• Bolt Hole Circle: 9 1/2"


• Magnet Diameter: 6 1/8"


• Mounting Depth: 6.81" (173 mm)


• Driver Displacement: 0.12 cu ft
