RATED SPEED 11000 RPM ± 15% at rated voltage
AIR FLOW 5.5 CFM
STATIC PRESSURE 0.20 Inch-H2O
ACOUSTIC NOISE 23.0 dB(A)
AIR FLOW V.S. PRESSURE See Page 5
INSULATION CLASS UL Class A
INSULATION RESISTANCE
PLASTIC HOUSING
10M ohm at 500 VDC between internal stator and
Lead wire (+)
DIELECTRIC STRENGTH Applied AC 500 V for one minute or AC 600 V for 2
Seconds between housing and lead wire (+)
LIFE EXPECTANCY 60,000 Hours at 40 deg. C, 65% humidity, 90% CL.
