I. Features
1. It can be used with common series chargers (such as IMAX B8) or independent chargers (such as UN A6) to charge 6 groups of the same type, the same number of sections of 2-6S battery packs in parallel balance. It can support 6 groups of 2S, or 6 groups of 3S, or 6 groups of 4S, or 6 groups of 5S, or 6 groups of 6S for parallel balance charging at the same time.
2. It can work with all the chargers with balance interface to balance charge lithium battery packs with the same number of sections (starting voltage, capacity, discharge multiplier allow certain differences) of no more than 6 groups at the same time. Avoid the trouble of replacing batteries many times.
3. The overall voltage value is more balanced and the average pressure difference is smaller after the multi-piece monomer is balanced with each other, which improves the charger's balancing efficiency and shortens the balancing time at the end of the charging period. And a single group of charging need to do 6 times to balance and use this product only need to do once to balance. Charging time is greatly reduced.
4. When 6 groups of batteries are connected in parallel at the same time, even if the batteries do not support high C-number charging can be safely balanced with the original single group charging current 6 times, the time to charge 6 groups of batteries is 1/6 of the original, which greatly shortens the charging time.
5. It can support up to 6 groups of 2-6S batteries with the same type and number of sections. The product is suitable for parallel connection of 1 to 6 groups of batteries (including LIPO, LIFE, LION) and can be balanced charging.
6. Comes with short circuit protection function
7. Support 3 sets of parallel charging boards combined use (can simultaneously charge 18 groups of batteries of the same nature).
8. It avoids overcharging of individual batteries, which improves the balancing efficiency and shortens the later stages of the balancing charging cycle.
9. The charging time is only the charging time of a single cell, thus saving charging time.
10. Avoid the trouble of replacing batteries repeatedly.
11. 20Z extra thick copper berth can withstand 80A current continuously.


*Protects the rechargeable battery in case of short circuit.
*Supports the combination of three parallel charging boards (i.e. can charge eighteen batteries of the same character at the same time).
*Using 2OZ thick copper foil, it can withstand 80A continuous current.
*It prevents each cell from being overcharged, thus increasing balancing efficiency and greatly reducing the late stage of the balancing charging cycle.
*It takes only 1/6th of the time it takes to charge each of the six batteries separately, saving total charging time.
*It avoids the hassle of replacing batteries over and over again.
*20AWG multi-stranded silicon wire for the balancing output cable.
*Main output cable is made of 14AWG multi-stranded high quality silicon wire.
*Equipped with safety T-plug silicone caps
*Uses high quality AMASS output plugs
