Description

Dauha OEM 5MP IR In/Outdoor Eyeball 2.8mm Fixed Lens CCTV Security Camera CVI





The Dauha 5MP HD eyeball security camera is a high-quality affordable solution to your home or business surveillance needs. It has an IP67 rating and is 100% protected against solid objects like dust and sand, and it has been tested to work for at least 30 minutes while under 15cm to 1m of water, so it can be used indoors or outdoors. The white color blends in nicely to many applications and can also see 98 feet at night with InfraRed technology.  The built-in mic allows the camera to capture audio so you can hear as well as see what is happening.





This Listing Includes:



(1) Eyeball Security Camera



(1) Installation wrench



(4) Phillips head screws



(4) Plastic anchors





Features



-Max. 20fps@5MP



Built-in mic (-A)



CVI/CVBS/AHD/TVI switchable



Max. IR length 30m, Smart IR



IP67, DC12V





TECHNICAL SPECIFICATIONS:



Image Sensor: 1/2.7 inch CMOS



Image Size: 2592 (H)1944 (V), 5MP



Electronic Shutter: PAL: 1/25s-1/100000s NTSC: 1/30s-1/100000s



Minimum Illumination: 0.02Lux/F1.85, 30IRE, 0Lux IR on



IR LEDs: 1



Smart IR: Support



IR On/Off Control: Auto/ Manual



Focal Length: 2.8mm; 3.6mm



Angle of View H: 113, V:60



Max. Aperture: F1.85/F2.0



Close Focus Distance: 1.3m(4.27ft)



DORI Distance:



2.8mm:       Detect: 56m (184ft)      Observe: 22m (72ft);         Recognize: 11m (36ft)     Identify: 6m (20ft);



3.6mm:       Detect: 80m (262ft)      Observe: 32m (105ft)       Recognize: 16m (52ft),    Identify:  8m (26ft)



Video Resolution



5M (25921944); 4M (25601440); 1080P (19201080);960H (960 576/960480)



Video Frame Rate



CVI:



PAL: 5M@20fp; 4M@25fp; 1080P@25fp



NTSC: 5M@20fp; 4M@30fp; 1080P@30fp



AHD:



PAL: 5M@20fp; 4M@25fp; 1080P@25fp



NTSC: 5M@20fp; 4M@30fp; 1080P@30fp



TVI:



PAL: 5M@20fp; 4M@25fp; 1080P@25fp



NTSC: 5M@20fp; 4M@30fp; 1080P@30fp



CVBS:



PAL: 960H



NTSC: 960H



Day / Night: Auto switch by ICR



BLC Mode: BLC / HLC / WDR(120dB)



White Balance: Auto; manual



Gain Control: Auto/Manual



Digital Noise Reduction: 2D NR



Motion Detection: Off / On (4 Zone, Rectangle)



Certifications: CE (EN55032, EN55024, EN50130-4)



                                FCC (CFR 47 FCC Part 15 subpartB, ANSI C63.4-2014)



                                UL (UL60950-1+CAN/CSA C22.2 No.60950-1)



Power Supply: 12V30% DC



Power Consumption: Max 3.7W (12V DC, IR on)



Operating Temperature: -40C to +60C (-40F to +140F); =less than 95% (non- condensaon)



Storage Temperature: -40C to +60C (-40F to +140F); less than 95% (non- condensaon)



Ingress Protection: IP67





Dimensions:



97.0mm85.8mm (3.82"3.38")



.



Weight:



Net Weight 0.22kg (0.49lb)



Gross Weight 0.28kg (0.62lb)
