Compact in size and powered directly from a USB 3.0 port, the converter is a practical easy-to-use USB 3.0 capture solution. It is compatible with Windows, Mac OSX, Linux, and Android operating systems, UVC-compliant, so it will work with all DirectShow compatible software.
The converter supports 1080p resolutions up to 60 fps. All SD / HD resolution signals are converted to 4:2:2 8-bit colour space over USB 3.0. The embedded audio in your SDI signal is extracted and output as two-channel LPCM. A USB 3.0 cable comes included.
Box Contains
-
INOGENI’s HD2USB3 HDMI to USB 3.0 video converter
- 1 x INOGENI HD2USB3
-
INOGENI’s HD2USB3 HDMI to USB 3.0 video converter
- 1 x INOGENI HD2USB3
| Brand | Inogeni |
| Model | INOGENI INOGENI-SDI2USB3 |
| MPN | INOGENI-SDI2USB3 |
| Type | Converter |
| Jitter (alignment): | HD/SD: <0.2 UI 3Gb/s: <0.4 UI |
| Cable Length: | 150m (492 ft) at 1.485 Gb/s 120m (393 ft) at 2.970 Gb/s |
| Frame Rates: | 60, 59.94, 50, 30, 29.97, 25, 24, 23.98 Hz |
| Colour Space: | YCbCr, 4:2:2 |
| Sampling Rate: | 148.5/148.35 MHz |
| Embedded Audio: | Ch 1&2 48kHz LPCM |
| Connector & Video Resolutions: | 1 x BNC (3GSDI active loop out) |
| USB - Connector & Video Resolutions: | 1 x USB 3.0 Type-B |
| USB - CODECs: | YUY2 4:2:2 8-bit for USB 3.0 MJPEG for USB 2.0* |
| Notes for MJPEG for USB 2.0: | *Devices having serial numbers >=SD2036xxx will support MJPEG over USB 2.0. Otherwise, it will be un |
| USB - Video Scaler: | Automatic hardware based |
| USB - Colour Space Conversion: | Automatic hardware based |
| USB - Sampling Conversion: | Automatic hardware based |
| USB - Frame Rate Conversion: | Automatic hardware based |
| Analog Audio I/O: | 2-channel LPCM audio from SDI |
| Audio Input Connector: | Ch 1&2 48kHz LPCM from SDI |
| Operating System: | No driver installation necessary. Windows 7 and above (32/64-bit) macOS 10.10 and above Linux (ker |
| Minimum Host Requirements: | USB 2.0 port - We recommend USB 3.0 for uncompressed video 4GB RAM Intel Core i5 or equivalent Graph |
| Motherboard: | Compatible with all motherboards. Intel, Renesas, ASMedia, and Fresco Logic. |
| Supported Cameras: | Cameras and camcorders with a SDI output |
| Software Compatibility: | UVC-compliant Runs with all software compatible to DirectShow, AVFoundation and V4L2 Compatible |
| Operating Temperature: | 0° to 45°C 32° to 113°F |
| Storage Temperature: | -40° to 105°C -40° to 221°F |
| Relative Humidity: | 0% to 90% non-condensing |
| Certifications | FCC, CE, RoHS, SoV, RCM, BSMI RoHS, BSMI, CB |
| TAA-Compliant: | Yes |
