DVR Specification:
Professional Remote Monitoring
Allowing users remotely access to the digital recorder anywhere with internet access. Use your phone ,tablet or computer to to view live picture or recorded footage at high definition. The smart playback control provided by the latest remote viewing application, allow users to view, edit, backup or take screenshots for a enhanced home security.
Allowing users remotely access to the digital recorder anywhere with internet access. Use your phone ,tablet or computer to to view live picture or recorded footage at high definition. The smart playback control provided by the latest remote viewing application, allow users to view, edit, backup or take screenshots for a enhanced home security.
Easy Set Up
Setting up your DVR system is quick and easy. Just install the DVR as instructed, connect the power supply and internet cable, and make a few personal settings via the set up wizard. No port forwarding is required. With this plug-and-play network set up, a QR Code Scan is provided for portable devices.
Setting up your DVR system is quick and easy. Just install the DVR as instructed, connect the power supply and internet cable, and make a few personal settings via the set up wizard. No port forwarding is required. With this plug-and-play network set up, a QR Code Scan is provided for portable devices.
Different Recording Modes
Record Continuous: Your DVR will continuously record regardless of what is Happening
Schedule Record: Record based on your own custom schedule time.
Motion Detection Record: The DVR will only record when motion is detected.
Recycle Record: Allows your DVR to overwrite the oldest video files on the hard drive.
4CH Govision 5MP DVR
| Specifications: GV3004-5MP | |
|---|---|
| Main Processor | Embedded processor |
| Operating System | Embedded LINUX |
| Video & Audio | |
| Input | 4 Channel, BNC |
| HDCVI Camera | 5MP, 1080P@25/30fps, 720P@50/60fps, 720P@25/30fps |
| AHD Camera | 5MP, 1080P@25/30, 720P@25/30fps |
| TVI Camera | 5MP, 1080P@25/30, 720P@25/30fps |
| CVBS Camera | PAL/NTSC |
| IP Camera Input | Up to 5MP |
| Audio In/Out | 1/1 RCA, Audio over co-ax supported on all BNC Channels |
| Two-way Talk | Reuse audio in/out, RCA |
| Display | |
| Interface | 1 HDMI, 1 VGA |
| Resolution HDMI | 2048x1536, 1920×1080, 1280×1024, 1280×720 |
| Resolution VGA | 2048x1536, 1920×1080, 1280×1024, 1280×720 |
| Display Split | 1/4/8/9 |
| OSD | Camera title, Time, Video loss, Camera lock, Motion detection, Recording |
| Recording | |
| Video/Audio Compression | H.265+/ H.265/ H.264+/ H.264 |
| Resolution | 2K, 1080P, 1080N, 720P, 960H, D1, CIF |
| Record Rate - Main Stream | 2K, 1080P (1~15fps), 1080N/720P/960H/D1/CIF (1~25/30fps) |
| Record Rate - Sub Stream | D1/ CIF (1~25fps) |
| Bit Rate | 32Kbps~6144Kb/s |
| Record Mode | Manual, Schedule (General, Continuous), MD (Video detection: Motion Detection, Video Loss, Tampering), Alarm, Stop |
| Record Interval | 1~60 min (default: 60 min), Pre-record: 1~30 sec, Post-record: 10~300 sec |
| Audio Compression | AAC(only for the 1st channel), G.711A, G.711U, PCM |
| Audio Sample Rate | 8KHz, 16 bit Per Channel |
| Audio Bit Rate | 64Kbps Per Channel |
| Video Detection | |
| Trigger Events | Recording, PTZ, Tour, Video Push, Email, FTP, Snapshot, Buzzer and Screen Tips |
| Video Detection | Motion Detection, MD Zones: 396 (22 × 18), Video Loss, Tampering and Diagnosis |
| Playback & Backup | |
| Sync Playback | 1/4/9 |
| Search Mode | Time/Date, MD & Exact search (accurate to second) |
| Playback Functions | Play, Pause, Stop, Rewind, Fast play, Slow play, Next file, Previous file, Next camera, Previous camera, Full screen, Repeat, Shuffle, Backup selection, Digital zoom |
| Backup Mode | USB Device/Network |
| Network | |
| Ethernet | RJ-45 port (100M) |
| Network Functions | HTTP, HTTPS, TCP/IP, IPv4/IPv6, Wi-Fi, 3G/4G, UPnP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPoE, DDNS, FTP, Alarm Server, P2P,IP Search |
| Max. User Access | 128 users |
| Smart Phone | iPhone, iPad, Android Phone |
| Interoperability | ONVIF 16.12, CGI Conformant |
| Storage | |
| Internal HDD | 1 SATA port, up to 6TB |
| Auxiliary Interface | |
| USB Interface | 1 USB Port (USB 2.0) |
| RS485 | 1 port, For PTZ Control |
| General | |
| Power Supply | DC12V/2A |
| Power Consumption | <10W (without HDD) |
| Working Environment | -10°C ~+55°C / 10%~90%RH |
| Dimensions | Compact 1U, 260mm × 236mm × 48mm |
| Weight | 1KG (with HDD) |
