The UltraSync ONE features one SYNC BNC output that supports genlock to any supported camera, provides word clock signals to a sound recorder or mixer, and can provide LTC (linear timecode) to a supported LTC device. The BNC LTC port provides input and output of LTC only.
The ONE can also be used as a master or slave, or in standalone mode. It can sync frame-accurate timecode using RF signals by pairing with multiple timecode sync devices such as the AtomX SYNC, UltraSync BLUE, or other RF timecode sync devices over a long range of up to 656'. Once the ONE is synced with the device, timecode is embedded in the recorded files and can be recognized by industry-standard software and NLEs (nonlinear editors).
A USB Type-C cable is included to charge the ONE, which features a built-in 800mAh LiPo battery that lasts up to approximately 24 hours.
- Synchronize timecode between devices such as cameras, audio recorders, and smartphones
- Use the UltraSync ONE as a master, slave, or standalone timecode sync device
- View synced timecode on the Ninja V monitor using AtomX SYNC
- One BNC SYNC port for genlock, LTC, or word clock output; one BNC LTC port for LTC input/output
- Timecode is embedded into the media file and automatically recognized by professional NLEs
- Can use long-range RF signals to sync multiple UltraSync ONE, AtomX SYNC, UltraSync BLUE, or other RF timecode sync devices
- Bright blue OLED display for timecode and status information
- Built-in 800mAh LiPo battery, charged via USB Type-C port, lasts up to approximately 24 hours
Box Contains
-
Atomos UltraSync ONE RF Timecode Sync for AtomX Sync and Ninja V
- USB Type-C Cable
- 2 x Mini-DIN to BNC Cable
-
Atomos UltraSync ONE RF Timecode Sync for AtomX Sync and Ninja V
- USB Type-C Cable
- 2 x Mini-DIN to BNC Cable
| Brand | Atomos |
| Model | Atomos ATOMSYON01 |
| MPN | ATOMSYON01 |
| Type | Professional Time Code Generators & Readers |
| Display Type | OLED |
| Display Resolution | 128 x 32 |
| Timecode | Free Run: TCX0 0.5 ppm Approximately 1 Frame Drift in 24 Hours 0 ppm Drift when RF Locked to Master |
| Output Connector | 1 x BNC SYNC (Genlock, LTC, Word Clock) |
| Input/Output Connectors | 1 x BNC LTC |
| Supported Frame Rates | 23.98 24 25 30D (Drop Frame) 30 29.97D (Drop Frame) 29.97 |
| Battery Type | Built-In Lithium-Ion Polymer (LiPo) |
| Battery Capacity | 3.7 V, 800 mAh, 2.96 Wh |
| Battery Charge Time | 3 Hours |
| Input Voltage | 5 VDC |
| Battery Run Time | ~24 Hours |
| RF Range | Up to 656' / 200 m |
| Number of Channels | Up to 14 |
| Frequency Range | 865.050 to 923.200 MHz |
| Power Connector | 1 x USB Type-C |
| Dimensions | 2.2 x 1.7 x 0.7 / 55 x 44 x 17 mm |
| Weight | 1.38 oz / 39 g |
