pair of 5x7" 70W RMS 4 Ohm 2-Way Coaxial Speakers with Kevlar Cone ZXI-57 DS18

DS18 ELITE 5x7" 2-Way Coaxial Speakers 70W RMS 4 Ohm with Kevlar Cone ZXI-574

This Listing Includes:

• (2) DS18 ELITE 5x7" Coaxial Speakers ZXI-574

Description:

Experience unparalleled sound with the DS18 ELITE 5x7" 2-Way Coaxial Speakers. Engineered for both casual listeners and hardcore audiophiles, these speakers deliver 70W RMS of pure audio power, bringing your music to life with remarkable clarity and depth. The Kevlar cone, renowned for its durability, pairs with a glass fiber construction to create a robust speaker that performs brilliantly even at lower power levels. With a sleek design and included black mesh grills, these speakers not only sound great but also look the part. Whether you're upgrading your car's audio system or building a high-performance setup, the DS18 ELITE speakers are your ticket to an immersive audio experience.

Features:

• Highly durable and extremely loud design built for both average and extreme audio systems.


• Glass fiber cone helps provide higher sensitivity and produces more sound even at lower power.


• Two-way design delivers a full range of frequencies with great sound quality.

GENERAL SPECIFICATIONS:

• Nominal Diameter: 5"x7"


• Nominal Impedance: 4 ohm


• RMS Power Handling: 70 Watts


• MAX Power Handling: 210 Watts


• Sensitivity (1w/1m): 91dB


• Frequency Response: 40Hz-20KHz


• Recommended HI Pass Crossover: 60Hz


• Speaker Type: 2-Way

MOTOR SPECIFICATIONS:

• Voice Coil Diameter: 1" / 25.5mm


• Voice Coil Former Material: KSV


• Winding Material: EISV


• Cone Material: Glass fiber


• Surround Material: Rubber


• Basket Material: Steel


• Magnet Material: Barium Ferrite


• Magnet Weight: 14.46 oz / 410g

TWEETER SPECIFICATIONS:

• Nominal Diameter: 1" (25.4mm)


• Voice Coil Diameter: 0.8" (20.4mm)


• Voice Coil Former Material: KSV


• Winding Material: EISVM


• Diaphragm Material: PEI


• Magnet Material: Neodymium


• Magnet Weight: 0.3 oz / 8.5g

THIELE & SMALL PARAMETERS:

• Equivalent Volume: 8.66L


• Excursion (one way): 2.7mm


• Free Air Resonance: 68Hz


• Mechanical Factor: 7.04


• Electrical Factor: 1.28


• Total Factor: 1.08


• Mechanical Mass: 258.7mm/N


• Mechanical Compliance: 4.66


• BL Factor: 4.44


• Voice Coil Inductance: 228mH


• Cone Area: 153.5cm


• DC Resistance: 3.5 ohm


• Mechanical Mass w/o air: 14g

DIMENSIONS:

• Overall Diameter: 5.55" x 7.60" / 141x193mm


• Overall Depth: 2.84" / 72mm


• Front Mount Baffle Cutout: 4.92" x 7.07" / 125x179.5mm


• Mounting Depth: 2.22" / 56.5mm


• Motor Diameter: 3.70" / 94mm
