OBDSTAR X300 Classic G3 A1+A2 Supports Programming of E-cars, Motorcycle, Marine (jet-ski)
(Cluster calibration functions can be added. Contact us for details)
X300 Classic G3 is the new generation intelligent scanner of OBDSTAR, which fully inherits the many advantages of OBDSTAR in automobile/commercial vehicle technology, such as wide coverage of car models and various functions, and comprehensively increases the progarmming functions of E-car, motorcycle, marine (jet-ski), etc. A good helper for automotive lo-cks.mith master.
Software Functions:
Support Progarmming IMMO(Keys), Remote Test, R/W Transponder, Make Dealer Keys, Make Start Keys, Renew Key, IMMO OFF, R/W EEPROM/MCU, Unlo-ck E-CU, E-CU Advanced, OBD II etc.
Hardware Advantages:
1. Built in CAN-FD, Fault Tolerant CAN, OBD16 Pinout Switch, DOIP, Remote Test and RFID;
2. RK3568 Hexa-Core Processor, 4G+64G Capacity Storage, High-brightness Display, HDMI High-definition Interface, Dual-band 2.4/5GHZ WIFI, Bluetooth 5.0, STM32H723 High Performance VCI Processor.
Product Features:
1. Support MOTO key progarmming (no need pincode) function for HARLEY, TRIUMPH, DUCATI, KAWASAKI, HONDA, SUZUKI, YAMAHA, BRP, INDIAN, DAYANG, APRILIA, PIAGGIO, VESPA, DERBY, GIRELLA, GUZZI, PEUGEOT, ITAJET and others;
2. Support Marine key progarmming function for BRP, KAWASAKI, YAMAHA and others;
3. Support E-Car key progarmming function for LI, NETA, LEAPMOTOR, SERES, AITO and others;
4. Support unlo-ck E-CU function for ALFAROMEO, FIAT, CHRYSLER, DODGE, JEEP and others;
5. Support progarmming solutions for SMART 453 that have lost all keys and all functions have been disabled;
6. Support progarmming solutions that have lost all keys and all functions have been disabled for R-ENAULT CITY K-ZE, KWID, SANDERO, TRAFIC, TWINGO, LODGY, DUSTER PH3;
7. Support pincode reading function that have lost all keys (No risk, and will not turn your car into a brick) for R-enault post-2015 ESPACE, KADJAR, KOLEOS, MEGAN, SCENIC, TALISMAN and Samsung QM6\SM6 models.
8. Paid software activation service for Cluster Calibration, E-CU Flasher, A-irb-ag Reset, Test Platform and the other functions are available.
Car/Motorcycle cluster recalibration: 589USD
E-CU flasher（Clone）:1080USD
A-i-rbag reset: 389USD
Test Platform: 550USD
9.Two Years free update. After that, 249 USD per year.
10.Language: ONLY English, can't change to other language.
Notice:
1. Language: English Only
Supported Vehicle Types:
Car, HD, E-Car, MOTO, Marine (jet-ski)
Function Display
1) Main Page
2) IMMO
3) Remote Test
4) RFID
5) E-CU Advanced
6) E-CU Flasher
Product Comparison:
| Products Details | X300 DP Plus C | X300 Classic G3 | |
| Hardware | Operation system | Android 5.1.1 | Android 11 |
| OTA | x | √ | |
| Screen recording | x | √ | |
| Wireless screen casting | x | √ | |
| CPU | qual core ARM cortex A9 1.4GHz | Quad-core 64-bit Cortex-A55 2.0GHz | |
| Battery | 3700mAh | 9000mAh | |
| Storage capacity | 1+32GB | 4+64GB | |
| LCD | 8.0 inch | 8.0 inch fully laminated sunlight readable screen | |
| Camera | Rear camera 500W pixels | Rear camera 800W pixels, auto-focus | |
| Bluetooth | Bluetooth 4.2 | Bluetooth 5.0(Compatible with BT 4.2) | |
| External interfaces | x | RJ-45√ | |
| x | HDMI√ | ||
| TYPE-A | TYPE-A,TYPE-C | ||
| WiFi | 2.4G | Dual-band 2.4G/5GHZ | |
| VCI | STM32F105 | STM32H723 | |
| CANFD Adapter Required | CANFD built in√ | ||
| x | DOIP built in√ | ||
| x | Low Speed(Fault Tolerant) CAN built in√ | ||
| x | RS232、RS485 built in√ | ||
| All other common protocol types | All other common protocol types | ||
| RFID | P001 Required | Built in√ | |
| Remote Test | RT100 Required | Built in√ | |
| Renault Converter | Renault Converter Required | Built in√ | |
| Weight | About 1kg | 1.5kg (main unit) | |
| Dimension | 254mm*174mm*35mm | 270.5mm*165mm*39mm | |
| Functions | Diagnosis | √ | x |
| OBDⅡ | √ | √ | |
| Car IMMO | √ | √ | |
| MOTO IMMO | √ | √ | |
| HD IMMO | √ | √ | |
| Marine IMMO | x | √ | |
| E-Car IMMO | x | √ | |
| RFID | x | √ | |
| Make key | x | √ | |
| Unlock Smart key | x | √ | |
| Renew key | √ | √ | |
| Read/Write EEPROM MCU | √ | √ | |
| E-CU advanced（Includes E-CU unlock） | x | √ | |
| Oil/Service reset | √ | √ | |
| Other service function | √ | x | |
| Remote test | x | √ | |
| E-CU flasher IMMO（IMMO OFF、ISN、IMMODATA） | x | √ | |
| E-CU flasher（Clone） | √ Limited supported models, different with DC706 and G3 | Paid activation | |
| Car/Motorcycle cluster recalibration | √ | Paid activation | |
| A-i-rbag reset | √ | Paid activation | |
| Test Platform | x | Paid activation |
Specifications:
Package Includes:
1pc x M001 main cable
1pc x charger
1pc x MP001 all-in-one progarmmer
1pc x W004 read/write soldering wire
1pc x W005 read/write soldering wire
1pc x W006 clock frequency wire
1pc x C4-01 multi-function data read/write board
1pc x C4-02 eight-pin chip(IC) soldering board
1pc x BENCH-A V3 for E-CM and T-CM cloning functions
1pc x P004 adapter
1pc x BENCH-B V2 E-CU Cloning BENCH harness
Free Gift Kits
A1
1pc x KeySim Kit
A2
1pc x M034 Harley-4+6
1pc x M037 Ducati-4
1pc x M040 BMW-10
1pc x M041 OBD-6
1pc x M042 INDIAN/VICTORY-8
1pc x M043 BRP-6
1pc x M053 HONDA IMMO
1pc x M054 SUZUKI/YAMAHA
