Digital Color Meter Tristimulus Colormeter Color Difference Tester Colorimeter

Note: Battery not Included During The Shipping !!!

Introduction:

▲The meter is an extremely compact, extremely easy-to-use tristimulus colormeter specially designed for measuring the color difference between two colors.

Feature:

▲Statistical function (Maximum, Minimum, Average and Standard Deviation).

▲Color difference tolerance set to perform PASS / WARN / FAIL.

▲Store 9 color-difference target colors.

▲User calibration function ensures higher accuracy; Auto memory (99 sets) & Read function.

▲Digital backlight display; Auto power off function.

Technical Specifications:

▲Display: Triple 4 digit LCD Display

▲Auto power off: Approx. 3 minutes

▲Data memory capacity: 99 set. (Direct reading from LCD display)

▲Low battery indication: √

▲Illuminating/Viewing geometry: 45°/0°: Illumination at 45°, measurement at 0°

▲Measuring area:Color difference: ∆(L*,a*,b*), ∆(E*ab,C*ab,H*ab), ∆(Y,x,y), ∆(X,Y,Z), ∆(Rs,Gs,Bs) or ∆(WI,YI,Tw), Color space: (L*, a*, b*), (L*, C*ab, hab), (Y, x, y), (X, Y, Z), (Rs, Gs, Bs) or (WI, YI, Tw)

▲Target color memory: 9 channel; set by measurement or keypad

▲Measuring range: L*: 5 to 100

▲Measurement conditions: Observe: CIE 2° Standard Observer

▲Illuminant: White LED lamp

▲Repeatability: Standard deviation within ∆E*ab 0.5 (Measurement conditions: Average of measurements of standard white plate)

▲Minimum interval between measurements: Approx. 2 seconds

▲Operating temperature and humidity: 0~40°C(32~104°F), < 85%RH.

▲Storage temperature and humidity: -10~40°C(14~104°F), < 70%RH.

▲Power: 4x1.5 AAA (UM-4) Battery (Battery Not Included In the Package)

▲Dimensions:140x73x35mm (5.5x2.9x1.4inches)

▲Weight(Not Including Batteries):Approx. 220g with battery

▲Standard Accessories: Main Unit, Measuring head, White calibration card, Carrying Case (B04); Manual

▲Optional Accessories：USB Data Cable with Software，Bluetooth Data Adapter with Software
