| Size | 0603 / 1608 Pre-Wired SMD LED |
|---|---|
| Color | Red |
| Luminosity/Brightness | 100-150 mcd |
| Forward Voltage | 9v-18v (volts) |
| Current | 20mA |
| Wavelength | 620-630nm |
| Viewing Angle | 105-120 Degrees |
| Mount Style | Custom |
| Lens Color | Clear |
| LED Brightness Class | Super/Ultra/Extreme |
| Brand | Lighthouse LEDs |
| Resistors Built In | Yes |
| Additional Resistors Required | No |
| Wire Length | Approximately 15cm (6 inches) |
| Shrink Wrapped Connections | Yes |
Lighthouse LEDs has been providing top quality components for over 20 years and have become the go-to supplier for many industries through Ebay and our personal website, where there is more ordering flexibility and products offered. If you need resistors, wire, heatshrink, switches or LED drivers you can find them at those links. We have, perhaps, the best and widest selection of LEDs out there!
These pre-wired 12V red 0603 SMD LEDs come with a built-in resistor and soldered leads, so they wire directly to any 12V source with no additional components required — ideal for console mods, guitar pedals, and custom lighting builds where board space is tight.
Each LED runs at 12V forward voltage with 20mA current draw, emitting a red wavelength of 625nm through a clear diffuse lens with a 110° viewing angle and 100–150 mcd brightness. The 0603 (1608 metric) footprint is one of the most common SMD sizes in consumer electronics, and the approximately 15cm (6 inch) pre-soldered leads make retrofits and point-to-point wiring practical without a reflow station.
Common applications
- Xbox 360 Ring of Light: The Phat RF board uses five 0603 LEDs (four quadrant rings plus one center power); red is a popular replacement color for the stock green. The Slim and E variants use eight SMD LEDs across the same ring layout.
- Xbox One / One S / One X power button board: Confirmed 0603 footprint; stock is white, red is a common accent mod.
- DualShock 3 player indicator LEDs: Four 0603 indicators per controller; burnout from repeated charging cycles makes these a frequent repair part.
- Nintendo Wii faceplate and disc slot LEDs: Power and disc illumination LEDs are 0603; red gives a distinctive look against the white shell.
- Boss guitar pedals (2017+ SMD production runs): The DS-1, BD-2, SD-1, and OD-3 moved to SMD PCBs in Malaysian production; the indicator LED is 0603 range. Note that pre-2017 Boss pedals use through-hole LEDs — check your board revision before ordering.
- Corsair mechanical keyboards (K65, K70, K90): Per-key SMD lighting uses 0603 footprint; individual dead key lights are a common repair target rather than full board replacement.
Wiring & power notes
DC power recommended: LEDs are designed for DC. Running on AC will cause flickering and reduce lifespan. If using a low-voltage AC source (model railroad transformer, DCC track voltage), convert it to DC with a MB1S bridge rectifier plus a 100µF 50V electrolytic capacitor for clean, ripple-free output.
Quality LEDs made in the USA since 2005.
