| Size | 0805 / 2012 Pre-Wired SMD LED |
|---|---|
| Color | Orange/Amber |
| Luminosity/Brightness | 150-250 mcd |
| Forward Voltage | 9v-18v (volts) |
| Current | 20mA |
| Wavelength | 600-610nm |
| Viewing Angle | 105-120 Degrees |
| Mount Style | Custom |
| Lens Color | Clear |
| LED Brightness Class | Super/Ultra/Extreme |
| Brand | Lighthouse LEDs |
| Resistors Built In | Yes |
| Additional Resistors Required | No |
| Wire Length | Approximately 15cm (6 inches) |
| Shrink Wrapped Connections | Yes |
Lighthouse LEDs has been providing top quality components for over 20 years and have become the go-to supplier for many industries through Ebay and our personal website, where there is more ordering flexibility and products offered. If you need resistors, wire, heatshrink, switches or LED drivers you can find them at those links. We have, perhaps, the best and widest selection of LEDs out there!
These pre-wired 12V orange amber 0805 SMD LEDs come ready to connect — with built-in resistors and ~15cm leads already soldered — making them a natural fit for any 12V project where you need warm amber or fire-toned light without calculating resistor values yourself.
Each LED measures 0805 (2.0mm × 1.25mm) with a clear diffuse lens, emits at 605nm in the orange-amber range, and runs at 12V DC with 20mA current draw. The 110° viewing angle spreads light broadly for indicator and accent use, and luminosity falls between 150–250 mcd — bright enough to see clearly, not so intense it overwhelms a scale scene or instrument cluster.
Common applications
- Scale modeling & dioramas: HO and N scale fire effects, incandescent window glow in vintage-era structures, locomotive cab lighting, or campfire simulations in diorama builds
- Automotive instrument clusters: Replacement amber warning indicators in VW/Audi dashboards (Passat, Golf, Beetle, A4/A6), GM truck gauge clusters, and similar vehicles where amber SMD indicators burn out over time
- Mechanical keyboard mods: Per-key backlight repairs or custom builds — 0805 is the standard footprint in Corne, Lily58, Sofle, and similar DIY keyboard PCBs; the pad size is forgiving for hand soldering
- Cosplay & prop building: Glowing embers, engine indicators, warning lights in sci-fi props, and wearable costume accents where a 12V battery pack is already in use
- Guitar pedal builds: Engaged/active indicators in DIY stompbox projects where amber suits the aesthetic better than red or green
- Arduino & maker projects: Status indicators on 12V-rail prototypes, custom PCB signal lights, or any breadboard build running off a 12V supply
Wiring & power notes
DC power recommended: LEDs are designed for DC. Running on AC will cause flickering and reduce lifespan. If using a low-voltage AC source (model railroad transformer, DCC track voltage), convert it to DC with a MB1S bridge rectifier plus a 100µF 50V electrolytic capacitor for clean, ripple-free output.
Quality LEDs made in the USA since 2005.
