| Size | 3mm Round Top Clear Flashing |
|---|---|
| Color | Blue |
| Luminosity/Brightness | 10,000-12,000 mcd |
| Forward Voltage | 3.0-3.4v |
| Current | 20mA |
| Wavelength | 460-465nm |
| Viewing Angle | 20-30 Degrees |
| Mount Style | Through Hole (DIP) |
| Lens Color | Clear |
| LED Brightness Class | Super/Ultra/Extreme |
| Animation Type | 6Hz Flashing / Blinking On / Off (Approximately 360 times a minute) |
Lighthouse LEDs has been providing top quality components for over 20 years and have become the go-to supplier for many industries through Ebay and our personal website, where there is more ordering flexibility and products offered. If you need resistors, wire, heatshrink, switches or LED drivers you can find them at those links. We have, perhaps, the best and widest selection of LEDs out there!
These 3mm blue extra-fast flashing LEDs self-oscillate at 6Hz with no external circuit required — just add power and a resistor, and they strobe on their own. That built-in flash rate makes them a direct fit for police/emergency lighting builds, RC cars, and any project where a rapid blue strobe is the effect you're after.
Each LED runs at 3.0–3.4V forward voltage at 20mA, emits at a wavelength of 462.5 nm (deep blue), and puts out a measured 10,000–12,000 mcd through a clear lens with a focused 25° viewing angle. The 3mm round-top package fits a standard 3.2mm (1/8") drill bit hole and drops into any build where a T-1 size LED is called for.
Common applications
- RC car police/emergency builds: Drill through polycarbonate body shells (3.2mm bit) and wire directly — standard on 1:10 truck and crawler police light bars. Yeah Racing-style LED kits use this exact footprint.
- Warhammer 40K lighting: Plasma cannon glow, force weapon OSL effects, Dreadnought eye sockets, and Thunderhawk cockpit accents — 3mm slots into most resin and plastic bases without modification.
- HO and N scale railroad signals: Crossing flashers, grade crossing signals, and emergency vehicle models on layouts. The 6Hz rate closely matches prototype US crossing flasher timing.
- Slot car track lighting: Police chase car builds for Carrera 1:32 Digital layouts running 12V DC — two LEDs in series with a 470O resistor is standard practice.
- Arduino/microcontroller prototyping: Use without a microcontroller for a standalone strobe, or drive from a GPIO pin for software-controlled override of the built-in flash pattern.
- Panel indicators and equipment repair: Replacement alert/status indicators in older test equipment, ham radio gear (Kenwood, Yaesu, ICOM), and PLC relay boards where a blue flash is used as an active-state indicator.
Wiring & power notes
Animated LEDs (flashing, flickering, fading) require DC — they will not operate correctly on AC power. If you are working from a low-voltage AC source such as a model railroad transformer or DCC output, convert to DC first with a MB1S bridge rectifier paired with a 100µF 50V electrolytic capacitor for smoothing. Without the capacitor, the animation pattern may glitch on the pulsed DC output of a bare rectifier.
Do animated LEDs work on AC power?
| Power Source | Bridge Rectifier | 100µF Capacitor |
|---|---|---|
| DC power supply | No | No |
| 12V AC landscape transformer | Required | Required |
| DCC track power | Required | Required |
Animated LEDs require DC. Convert AC sources to DC using a bridge rectifier plus a 100µF smoothing capacitor for clean, ripple-free animation.
Resistor quick reference — 3V LEDs (blue, green, white, UV) at 20mA:
| Supply Voltage | Resistor | Power Rating |
|---|---|---|
| 4V | 56Ω | 1/4W |
| 5V | 100Ω | 1/4W |
| 6V | 150Ω | 1/4W |
| 7V | 200Ω | 1/4W |
| 8V | 270Ω | 1/4W |
| 9V | 300Ω | 1/4W |
| 10V | 360Ω | 1/4W |
| 11V | 430Ω | 1/4W |
| 12V | 470Ω | 1/4W |
| 13V | 510Ω | 1/4W |
| 14V | 560Ω | 1/2W |
| 15V | 620Ω | 1/2W |
Prefer not to calculate resistor values? Our 20mA LED Current Limiter eliminates the math entirely. Active constant-current drive to 20mA across a 4–45V DC supply — ideal for automotive circuits where voltage fluctuates. Multiple LEDs in series share one driver.
Building with this item
Need supporting components? These pair directly with this listing:
- Panel mount holder (Black): 3mm LED Holder/Bezel (Black) — through-panel bezel with lock ring and insert
- Panel mount holder (Chrome): 3mm LED Holder/Bezel (Chrome) — silver/chrome finish alternative
