Application:

For Eaton Char-Lynn 2000 Series

OE/Part number:

104-1229-006,104-1229,1041229006,1041229

Specification:
Condition: Brand new
Color: Black
Material: Iron
Displacement: 393.8cm3/r [24.03 in3/r]
Mounting type: 2 bolt standard- 82.6 [3.25] Pilot Dia. 13.59 [.535] Dia. Holes on 106.4 [4.19] Dia. Bolt Circle
Output Shaft: 31.75 [1.250] Dia. Flat Root Side Fit, 14 Tooth, 12/24 DP 30 DEG. Involute Spline With .375-16 Unc-2B Thread In End, 33.0 [1.30] Minimun Full Spline Length
Ports: 875-14 unf-2b Sae O-ring Ports - Staggered ports
Fitment type: Direct replacement

Feature:
1.  Stable characteristics, high reliability.As an executive component of the hydraulic system, the motor can effectively convert the liquid pressure energy provided by the hydraulic pump into the mechanical energy (torque and speed) of its output shaft, thus providing sufficient energy.
2.  Made of high-strength iron housing, protecting the shaft inside very well, solid and durable, long service time.The bearings make the hydraulic motor have a strong radial force. Good Sealing Performance: The rubber sealing ring can effectively avoid oil leakage, not only ensuring a smooth use process but also saving you cost.

3.High Precision.The oil pan, stator, rotor pair, and output shaft inside ensure the high precision of the hydraulic gerotor motor and make your use more accurate.

4.Application Extensive：It applies to industrial, logistics, agricultural, refitting, engineering machinery, industrial machinery, construction machinery, shipbuilding and aviation, harvester equipment, excavator equipment, light machinery equipment, various types of automobiles, and more.

Package included:
2x Hydraulic Motor
（Showing as the picture）

Note:
1. No instruction included.
2. Professional installation of the product is highly recommended.
3. Please double confirm the compatibility as well as the OEM number before purchasing.
