Self-aligning ball bearings with seals on both sides are designed with two rows of balls, a common sphered raceway in the outer ring, and two deep, uninterrupted raceway grooves in the inner ring. These bearings are insensitive to angular misalignment of the shaft relative to the housing, making them ideal for compensating for shaft deflection or misalignment. They accommodate both static and dynamic misalignment, providing excellent high-speed and light load performance with low friction for smooth, efficient operation. The integral sealing system keeps lubricant within the bearing, prevents contaminants from entering, and reduces maintenance needs, significantly prolonging bearing service life.
Responsive image

2200-2RS, 2200-2RSR-TVH, 2200 E-2RS1TN9 Self-aligning Ball Bearing 10x30x14mm (Qty 1)

  • Self-aligning ball bearings with seals on both sides.
  • Designed with:
    • Two rows of balls
    • A common sphered raceway in the outer ring
    • Two deep, uninterrupted raceway grooves in the inner ring
  • Insensitive to angular misalignment of the shaft relative to the housing, ideal for compensating for shaft deflection or misalignment.
  • Key performance benefits:
    • Accommodate static and dynamic misalignment
    • Excellent high-speed performance
    • Excellent light load performance
    • Low friction for smooth, efficient operation
  • Integral sealing:
    • Keeps lubricant within the bearing
    • Prevents contaminants from entering
    • Reduces maintenance needs and prolongs bearing service life

Features:

  • 2200-2RS Self-aligning Ball Bearing dimensions: Bore Diameter 10mm, Outside Diameter 30mm, Width 14mm. It is made of 100% Chrome Steel and Pre-Lubricated with High-Quality Grease, ideal for use in High, and Low-temperature settings.
  • Interchange to 2200, 2200 TV, 2200-TVH, 2200-2RS-TVH, 2200 ETN9, 2200 E-2RS1TN9, 2201 TNG, 2201-2RSTNG, 2200 EEG15
  • This self-aligning ball bearing has two rows of balls and a common spherical outer raceway. It also has a rubber seal on both sides connected to the inner ring to stop dust from entering. If your application requires a ball bearing with one seal or opened without seals, you can easily remove one or both seals.
  • Application: Industrial Applications, Food & Beverage, Furnaces, Transmissions, Gearboxes, Elevators, Lifts and Hoists, Sporting Machines, Medical Devices, Automotive, Agriculture Machines...etc
  • Specializing in the Exclusive Production of Bearings with High Performance, High Speed, Less Vibration, Low Noise, and Long Life.

Product Details

Specifications

Item  2200 TV-2RS
Bearing Type  Self-aligning ball bearing
Bearing Type  2200
Bore Diameter  10.00mm
Outside Diameter  30.00mm
Width  14.00mm
Width Inner Ring  14.00mm
Width Outer Ring  14.00mm
Dynamic Load Rating Cr  5530 N
Static Load Rating Cor  1180 N
Limiting Speed  17000 r/min
Clearance  CN
Tolerance Classes  P5
Cage  Non-metallic
Closures  Seal on both sides
Lubrication Type  Grease Chevron
Lubrication Temperature  -30°C to +180°C
Rolling Element Indicator  Ball
Material  Gcr15
Product Weight  0.048 KG

Interchange

FAG 2200-2RSR-TVH
Koyo 2200 2RS
NSK 2200-2RSTNG
NTN 2200 LLU
SKF 2200 E-2RS1TN9

OEM

Application

Application Application

You can use this DEEP GROOVE BALL BEARING as a Replacement Part for:

  • Industrial Applications
  • Furnaces
  • Transmissions
  • Gearboxes
  • Robots
  • Elevator
  • Lifts and Hoists
  • Moulding Machines
  • Polishing Equipment
  • Rolling Mills
  • Aggregate Crushers
  • Agriculture Machines
  • Irrigation Machinery
  • Sewing Machines
  • Mining Construction Equipment
  • Medical Devices
