Title NEW STARTER REPLACEMENT FOR CASE GEHL KUBOTA 2280004572, 2280004750, V2203, 1542563010, 15425-63011, SND0406, 41052225, 41052567

NEW STARTER REPLACEMENT FOR CASE GEHL KUBOTA 2280004572, 2280004750, V2203, 1542563010, 15425-63011, SND0406, 41052225, 41052567

Item specifics

condition	NEW
Manufacturer Part Number
Brand	RCPS

100% SATISFACTION GUARANTEED

Specifications
Interchanges
Applications

Specifications

OE Manufacturer:	DENSO
Product Type:	Starter
Weight:	11.1000
Condition:	NEW
Unit Source:
Design / Type:
Design / Type:	OSGR
Design / Type:
Starter Series:
Location - General:
Location - Specific:
Design Type:
Voltage:	12
Amperage:
kW:	2.0
Rotation:	CW
Regulator/Fan:
Tooth Count:	9
Spline Count:
Polarity:
Shaft Type:
Duty Cycle:
Horsepower:
RPM:
V-Set:
Circuit Type:
Plug Code:
Plug Orientation:
Pulley Class:
Case OD (mm):
Overall Length (mm):
Gear OD (mm):
Pulley Belt Width (mm):
Pulley OD (mm):
Shaft Overall Length (mm):
Shaft OD (mm):
Clutch Type:
Operating Mode:
Pads Included:
Connection Type:
Piston Material:
Piston Outside Diameter (in):
Bleeder Port Measurment:
Inlet Port Measurement:
Ignition Type:
Housing Material:
Torque (ft. lbs):
Pulley OD (in):
Crankshaft OD (in):
Terminal Type:
Sensor Included:
Idle ACM Included:
Cage Wheel Included:
Wiring Harness Included:
Number of Pistons:
Caliper Pistion OD (mm):
Motor Overall Length (in):
Motor OD (in):
Wheel OD (in):
Bearing Inside Diameter (mm):
Bearing Outside Diameter (mm):
Bearing Width (mm):
Rotor Inside Diameter (mm):
Rotor Outside Diameter (mm):
Rotor Overall Length (mm):
Rotor Shaft Outside Diameter (mm):
Rotor Shaft Overall Length (mm):
Mounting Hardware Included:	No
Installation Hardware Included:
Mounting Type:
Mounting Type:
Mounting Type:
Cap Design:
Plunger Type:
Includes:
Includes:
Number of Mounting Holes:	2
Number of Terminals:
Number of Wires:
ETB Inside Diameter (in):
Unit Finish:	Same as OE
Unit Color:
Number of Pieces:	1
Country of Origin:	CN
Country of Use:
Notes:
Other Part #:	18004, SND0406, 18004S, 410-52225, 410-52567

Interchanges

Case: 126895A1

Kubota: 15425-63014, 15425-63015, 15425-63016, 17490-63014, 1K371-63010

Denso: 228000-4570, 228000-4571, 228000-4572, 228000-5273

Prestolite: 20513033

Lester: 18004

Arrowhead: SND0406

BBB HD: 18004

Carquest HD: 18004S

J & N Automotive: 410-52225, 410-52567

Denso Remanufactured: 9722809-457

NAPA HD: 18004

NAPA New HD: 18004N

NAPA Pro Series: 18004

Tisco: SND0406

Wilson HD New: 91-29-5323N

Wilson Heavy Duty: 91-29-5323

Dixie Electric: S-8676

Lucas Electrical Europe: LRS01325

Andre Niermann: 014750

Applications

Make	Model	Year	Engine	Remarks
Case	1838	95-99	All	Kubota Engine Denso OSGR, 9T
Case	560	94-01	All	Kubota V2203 Dsl Denso OSGR, 9T
Case	6010	97-07	All	Kubota V2203 Dsl Denso OSGR, 9T

*NOTE: "M.T" Indicates Manual Transmission / "A.T" Indicates Automatic Transmission*
Please Reach Out To Customer Service To Confirm Fitment, If Necessary.
