ASAHI
Actuated Diaphragm Valve, 1-1/2" Type 14 Flange Valve with PVC Body
PP Type-14 Pneumatic Actuated Diaphragm Valve Air-Air
Valve/Actuator PN: 02D00014G
ASCO Metering Solenoid Valve PN: WTX8401B20218879 (20-150 psi) 110/120V
NEW VALVE , ACTUATOR, & METERING SOLENOID
Please Read
(Valve has some very minor shelf wear from sitting out of the box but,
the valve and it's components, are new, guaranteed, and ready to put into service.)
ASAHI - 02D00014G - 1-1/2 FLANGED Type-14 Pneumatic Actuated Diaphragm VALVE
Specifications
Type of product Actuated Diaphragm Valve
Manufacturer Asahi/America
Size 1-1/2"
Diaphragm Material EPDM
Maximum Psi 90 psi
Minimum Psi 60 psi
Actuator Type Pneumatic Actuator
Airport Size 1/4" NPT
Connection Type Flange
Housing Material Glass-Filled polypropylene
Body Material PVC
Valve Series Type 14
Valve Type Diaphragm Valve
Description
Compact Pneumatic Type-14 Diaphragm Valve
The Type-14 diaphragm valve is available with an optional pneumatic actuator for operation via a pressurized air supply. The pneumatic actuator is available in both air to air (double acting) and air to spring (single acting) styles. The actuator replaces the valve bonnet and is an integral part of the valve. The actuator is operated with a Nitrile diaphragm which is connected directly to the valve diaphragm for quick response times. The NAMUR mounting pattern on the top of the actuator gives the option for mounting limit switches, positioners and/or a solenoid for automation. The housing is made from glass filled polypropylene for high strength and chemical resistance. A visual position indicator at the top of the actuator allows the user to confirm the valve position.
Ideal Applications Include:
Chemical processing, bleach plants, aquariums, mining, water treatment, landfills, swimming pools, power plants
Features & Benefits:
Rugged solid thermoplastic construction for maximum corrosion resistance
Uniquely designed body and bonnet together with diaphragms of new sealing designs by the state of the art computer aided analysis for superior sealing
Weir design for excellent throttling characteristics
NAMUR pad mount for easy installation of solenoid valves
Full vacuum rating
Bubble tight sealing, even in applications such as slurries or high suspended solids count
Bonnet seals to protect internals from corrosive environments
Adjustable travel stop to prevent diaphragm from being over-tightened
Bayonet structure to connect compressor and diaphragm for quick maintenance
Integrally molded bottom stand for simple yet firm panel mounting
Indicator at the top for valve position
PTFE diaphragms have a three layer design with a PVDF gas barrier separating the EPDM backing cushion. This prevents corrosive gases that permeate the semi-permeous PTFE material from attacking the EPDM backing cushion
Low profile
