All modifications must be installed by licensed mechanics and in compliance with your local modification regulations

​​​​​​​

Frame Shortening Kit Short Bed Conversion for 1963-72 C10 This kit converts 1963-72 C10 long bed trucks to short bed configuration.It includes a laser etched steel template with all hole locations marked, a strength steel inner “C” channel brace, and all necessary hardware for installation.The kit is compatible with 3/4 ton coil spring trucks.For 1967-72 3/4 ton trucks, the mounting points must be changed to match 1/2 ton C10 mounts.The driveshaft must be shortened before reinstallation.It is not designed for 133" wheelbase trucks or 4x4 trucks.Welding is required during installation.Short bed parking brake cables and lines are required.The conversion changes the wheelbase from 128" to 115".Features include templates for cutting and drilling the frame, a 1/4" thick plate, laser cut C-channel for reattaching the shortened frame, and Grade 8 mounting hardware.

Application:

1. For Chevy, For GMC C10 1963-72 Welding Required

2. Will Also Work on 3/4 Ton Coil Spring Trucks, 67-72 3/4 ton trucks will require changing the Cab Mounts to 1/2 ton C10 Mounts

3. Driveshaft will need to be Shortened before re-installation

4. Not designed to work on 133" wheelbase trucks

5. Will not work on 4x4 Trucks

6. Specifically Engineered For 1963-1972 Chevy C10 Long Bed To Short Bed Shortening Conversion Kits

7. Requires Short Bed Parking Brake Cables and Lines

8. Converts 128" Wheelbase Trucks to 115" Wheelbase

Specification:

Type: Frame Shortening Kit

Material: Steel

Color: Bare Metal

Plate Thickness: 1/4"

Placement on Vehicle: Rear

Fitment Type: Performance/Custom

Condition: 100% Brand New

Warranty: 2 Years

Package Included:

1x Frame Shortening Kit

Features:

1. Designed specifically for C10 trucks manufactured between 1963 and 1972.
2. Converts long-bed chassis to short-bed configuration using frame mounting points.
3. Includes all necessary brackets, hardware.
4. Maintains factory ride height and suspension geometry after frame shortening.
5. Compatible with both standard and heavy-duty axle configurations found on C10 models.
