Panduit LCDX4-14B-L Compression Lug Standard Copper 4 AWG 2-Hole 1/4" Stud Gray
Click Thumbnails to Enlarge
DESCRIPTION
• Panduit LCDX4-14B-L Compression Connectors - Lugs.
• Panduit Compression Lug Connector, 2-Hole, Series: LCDX, Extra-Flexible/Flexible/Stranded Copper Conductor, 3 AWG, 4 AWG, 5 AWG Conductor, Die Code: P29, 35 kV, 1/4 in Stud, Standard/Straight Tongue, 0.55 in W x 0.09 in THK Tongue, 2.1 in Overall Length, Standard/Inspection Window Barrel, 0.28 in ID x 0.38 in OD x 0.53 in L Barrel, 3/4 in Stud Hole Spacing, 5/8 in L Wire Strip, Tin Plated, 90 deg C, 42.952 in Mounting Hole, Copper, Gray.
FEATURES
• Inspection window to visually assure full conductor insertion.
• Tin plated to inhibit corrosion.
• Color-coded barrels marked with PANDUIT and specified competitor die index numbers for proper crimp die selection.
• Can be used with code conductor and flex conductor class G, H, I, K, M and diesel Locomotive.
• Generously beveled wire entry prevents bent back strands when inserting conductor into barrel.
PRODUCT SPECIFICATIONS
| Product Type | Compression Lug |
|---|---|
| Base Material | Copper |
| Number of Stud Holes | 2 |
| Barrel Type | Standard Barrel Length with Inspection Window |
| Barrel Entry | Beveled |
| Tongue Type | Standard |
| Tongue Angle | Straight |
| Inspection Window | Yes |
| Finish/Coating | Tin-Plated |
| Stud Hole Size (In.) | 1/4 |
| Stud Hole Spacing (In.) | 0.75 |
| Copper Code Conductor Size (AWG) | 4 |
| Barrel Length (In) | 0.53 |
| Tongue Width (In) | 0.55 |
| Tongue Thickness (In) | 0.09 |
| Overall Length (In) | 2.1 |
| Panduit Die Index Number | P29 |
| Wire Strip Length (In) | 5/8 |
