IstaBreeze® Windsafe 2000W – 230V Plug-In Wind Turbine System
A Grid-Compatible, High-Efficiency Wind Energy Solution for Residential Use

The IstaBreeze® Windsafe 2000W Wind Turbine represents an advanced and fully integrated solution for environmentally responsible electricity generation.Equipped with a brushless, gearless permanent magnet generator and featuring an aerodynamic tilting mechanism, the Windsafe series delivers exceptional efficiency, long-term reliability, and operational safety even in challenging weather conditions. This system is meticulously engineered to deliver efficient, stable, and safe wind power directly to the public grid via a standard 230V AC household socket, eliminating the need for external energy storage systems or complex electrical infrastructure.

Core System Attributes

Nominal Output Power – 2000W:

With a rated power output of 2000 watts, the Windsafe turbine is capable of delivering a significant share of household energy needs. This high performance ensures both cost-effectiveness and strong energy yield, even under variable wind conditions.

Direct Grid Feed-in (230V):

The system is designed for plug-and-play operation, allowing users to connect the inverter directly to a standard household socket (Schuko or equivalent). This feature greatly simplifies installation and reduces the cost and complexity typically associated with renewable energy systems.

Integrated Tilting Safety Mechanism:

The turbine is equipped with an innovative Tilting Device that automatically adjusts the rotor axis in response to high wind speeds or gusts, thereby reducing mechanical stress and minimizing the risk of overload or structural fatigue. This mechanism extends the lifespan of the turbine and enhances operational safety.

Built-in Inverter with Dump Load Controller:

The included SUN-2000G2-WAL-H inverter is specifically matched to the wind turbine’s electrical output. It includes an integrated dump load controller, limiter sensor, and various protective functions (e.g., overload, islanding, short circuit), which ensure safe and reliable operation under all wind conditions. The dump load stabilizes the rotor speed and prevents runaway operation, which is critical for both safety and efficiency.

2000W AC Wind Turbine Grid-Tie Inverter with Limiter Sensor & Dump Load | 48V 3-Phase | Plug & Play

Unlock the power of renewable wind energy with this high-performance grid-tie inverter system. Designed for ease of use and maximum efficiency, this inverter offers safe and stable energy feed-in to the public grid – ideal for residential applications.

✅ Key Features

• Plug & Play Installation – No technical setup required. Just connect and start generating.
• Auto Recognition – Automatically detects system parameters for optimal performance.
• User-Friendly Design – No complex configuration needed.
• Built-in Dump Load Controller – Automatically manages excess power and prevents overloads.
• Limiter Sensor – Ensures energy is only fed into the grid when it exceeds household consumption.
• WiFi-Ready – Optional module allows wireless monitoring (module not included).
• VDE Standard Approved – High efficiency and safety compliance.

⚡ Technical Highlights

• Compatible with 48V 3-phase AC wind turbines
• Inverter input voltage range: AC25.9V ~ 51.96V
• Parallel connection supported on AC side
• Island protection, overload, and reverse polarity protection
• 2-year warranty + lifetime technical support
• Each unit tested for 20+ hours before dispatch

⚠️ Note: Not compatible with DC input sources.

✅ Choosing the Right Voltage

To match your turbine, calculate the AC voltage from its DC output using this formula:
V(AC) = V(DC) ÷ 1.732

Example: A 48V wind turbine with a DC output of 45–90V corresponds to ~AC25.9V–51.96V.

This inverter is the ideal solution for anyone wanting to maximize the use of wind energy in a safe, efficient, and plug-and-play format.

🔧 Technical Specifications – IstaBreeze Grid-Tie Inverter


Note: The WLAN module is not included in delivery, please purchase separately.

Why Choose This Product?

With trusted IstaBreeze quality, this inverter set allows you to harness wind energy safely and efficiently. The built-in limiter sensor ensures that only excess power is fed into the grid—slowing down your electricity meter and maximizing self-consumption. The integrated dump load controller protects your system from overvoltage, making it a smart, worry-free solution. Easy to install, no technical skills required.
