Key Points:

- This monoblock valve is a hydraulic directional control valve. These valves are used to start and stop fluid flow into hydraulic cylinders or hydraulic motors.

- 2 Spool valve with compact design allows for installations in tight areas
- All spools are standard double acting with spring return to neutral position which are ideal for double acting cylinders
- Used for open center systems (Pump to Tank Flow)
- Anti-drop load checks on each spool
- Precision ground and hard chrome-plated spools assure a long life
- High-tensile strength cast iron monoblock construction
- SAE O-Ring ports ensure solid seal and prevent blockages
- Capable of Closed Center or Power Beyond (conversion plug required)
- Vertical or horizontal handle mount
- Adjustable Relief Valve Range:  1500 to 3625 PSI
- Used as motor or single-acting spool possible (#10 SAE port plug required)

Key Features:

- Double Acting : Hydraulic control valve for operating double acting cylinders.

- Durable Quality : This hydraulic directional control valve comes with 2 spool, with cast iron construction for long-time use.

- Spring Return : All spools are standard double acting with spring return to the neutral position which is ideal for double-acting cylinders.

- High-Efficiency : The relief valve range is up to 3625 PSI and the maximum flow is up to 21 GPM.

- Wide Application : Fit for small tractors, tractors loaders, log splitters, and etc.

Details:

- Max Operating Pressure: P = 3625 PSI, T = 725 PSI, A & B = 4350 PSI
- Flow Rating: 21 GPM (80 l/min)
- A & B Work Ports:  #10 SAE O-Ring (7/8”-14) Thread
- Inlet Port: #10 SAE O-Ring (7/8”-14) Thread
- Outlet Port: #12 SAE O-Ring (1-1/16”-12) Thread
- 3 – 5/16” Mounting Holes

Common Uses:

- Operate hydraulic cylinders (Double-Acting or Single-Acting)
- Operate hydraulic motors ("D" Spool Required)
- Install rear remotes on a tractor

Package Including:

- 1×2 Spool 21GPM Hydraulic Directional Control Valve
