Olidesmart WIFI Smart Wireless Receiver&Controller for Automatic Door System

Workable with Olide Access Control Device Model 202G,602H,505MHW,510,511,508,512N,512,272,270

With WIFI Smart function,can open auto door by phone APP,work with Alexa,google home etc
Adopt 2.4G wireless communication technology,good frequency consistence,high wireless transmitting and receiving stability
Large capacity output,can be equipped with automatic door,electric lock and access controller
After receiving the signal,output door opening signal for 1.5s,and equipped with buzzing,receiving indicator and LED indicator
The receiver with wide voltage input design,DC12-30V power input

Technical specification:

Model: Olide-510FW

Power Supply: AC/DC 12-30V

Static Current: 65mA(DC12V)

Dynamic Current: 140mA DC12V

Connection Capacity: 3A DC30V

WIFI Function: Only 2.4G routers can be connected External

Dimension: 123mm(L)X50mm(W)X32mm(H)
